Name: 1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar
Brand: Ningbo Brando Hardware Co., Ltd
SKU: 19.13BAS
Price: 26.00 USD
Availability: InStock

Home Products Stainless Steel Solenoid Valve

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

Product Details:

Place of Origin:	Ningbo, China
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	19.13BAS

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	7 working days
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	200000pcs per month

Contact Now

Detailed Product Description

Product Name:	Solenoid Valve	Port Size:	1/8'', 1/4''
Orifice Size:	1.2mm, 1.5mm, 2mm, 2.5mm, 2.8mm	Body Material:	Stainless Steel 304
Seal Material:	NBR (Standard), EPDM, FKM (Optional)	Working Media:	Air, Water, Steam, Gas, Liquid, Light Oil, Etc
Media Temperature:	NBR (-10 To +80℃), EPDM (-30 To +120℃), FKM (-30 To +150℃)	Working Pressure:	0 To 30 Bar
Operation:	Plunger Direct Acting	Function:	2 Way Normally Open
Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Highlight:	Normally Open Stainless Steel Solenoid Valve , 1/8'' Stainless Steel Solenoid Valve , 2 Way NO Solenoid Valve

1/8'' 1/4'' 2 Way Normally Open Stainless Steel Solenoid Valve 30bar

This is a small and compact solenoid valve, 1/8'' or 1/4'' port, 1.2 to 2.8mm orifice, 0 to 30 bar, plunger direct acting, 2 way normally open, stainless steel 304 body, NBR standard seal, can be customized as EPDM or FKM seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.

Technical Data:

Model No	Port Size (inch)	Orifice Size (mm)	Cv	Working Pressure (bar)		Body	Seal	Voltage
Model No	Port Size (inch)	Orifice Size (mm)	Cv	DC	AC	Body	Seal	Voltage
2 Way Normally Closed, Direct Acting
19.13BAX012BXX	1/8'' 1/4''	1.2	0.09	0 to 30	0 to 30	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BAX015BXX		1.5	0.11	0 to 30	0 to 30
19.13BAX020BXX		2.0	0.15	0 to 20	0 to 15
19.13BAX025BXX		2.5	0.18	0 to 14	0 to 10
19.13BAX028BXX		2.8	0.25	0 to 10	0 to 8
2 Way Normally Open, Direct Acting
19.13BBX012KXX	1/8'' 1/4''	1.2	0.09	0 to 10	0 to 10	Brass SS304	NBR EPDM FKM	12VDC 24VDC 24VAC 110VAC 220VAC
19.13BBX015KXX		1.5	0.11	0 to 9	0 to 9
19.13BBX020KXX		2.0	0.15	0 to 6	0 to 6
19.13BBX025KXX		2.5	0.18	0 to 4	0 to 4
19.13BBX028KXX		2.8	0.25	0 to 3	0 to 3
