KVD 12 1/2'' Danfoss Type Receiver Pressure Regulator 034L0173 034L0176

KVD 12 1/2'' Danfoss Type Receiver Pressure Regulator 034L0173 034L0176

KVD is a modulating receiver pressure regulator. It opens on falling receiver pressure and bypasses hot gas to maintain the receiver pressure at the regulator setting (adjustable). The receiver pressure regulator KVD opens at a fall in pressure on the outlet side, i.e. when the pressure in the receiver falls below the set value. KVD regulates only in dependence on the outlet pressure. Pressure variations on the inlet side of the regulator do not affect the degree of opening since KVD is equipped with an equalization bellows. This bellows has an effective area corresponding to that of the valve seat. The KVD regulator is also equipped with an effective damping device against pulsations which can normally arise in a refrigeration plant. The damping device helps to ensure long life for the regulator without impairing regulation accuracy.

Technical Data:

Ordering Code:

Dimension:



Solenoid Valve	4 Way Reversing Valve	Expansion Valve	Hot Gas Bypass Valve
Ball Valve	Check Valve	Sight Glass	Access Valve



Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
