1-1/2'' DN40 Flange Hot Water Steam Brass Solenoid Valve 220VAC 110VAC 24VDC

1-1/2'' DN40 Flange Hot Water Steam Brass Solenoid Valve 220VAC 110VAC 24VDC

Product Features:

1. Working Medium: Steam, Hot Water, High Temperature Liquids, etc
2. Working Pressure: 0.5 to 15 bar
3. Medium Temperature: +5 to +180℃
4. Pipe Connection: Flanged
5. Port Size: 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''
6. Orifice Size: 17mm, 22mm, 30mm, 38mm
7. Body Material: Brass
8. Seal Material: PTFE
9. Function: 2 Way Normally Closed
10. Operation: Piston Pilot Operated
11. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Technical Data:

US-40F Dimension:

Our Production:

More Steam Solenoid Valves:

1/2'' to 2'', 16 bar	1'' to 2'', 16 bar	3/8'' to 2'', 16 bar	3/8'' to 2'', 25 bar
