200 bar Water Air Gas High Pressure Solenoid Valve 1/4'' 3/8'' 12VDC 24VDC

200 bar Water Air Gas High Pressure Solenoid Valve 1/4'' 3/8'' 12VDC 24VDC

Product Features:

1. Working Medium: Air, Water, Gas, Liquid, etc
2. Working Pressure: 0 to 300 bar
3. Medium Temperature: -10 to +180℃
4. Port Size: 1/4'', 3/8''
5. Orifice Size: 1mm, 1.5mm, 2mm, 2.5mm, 3mm, 4mm
6. Body Material: Stainless Steel 304
7. Seal Material: PTFE
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data:

Main Dimension:

Our Production:

FAQ:

Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.

Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.

Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.

Similar Products:

Max 200 bar	Max 200 bar	Max 300 bar	Max 360 bar

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
