| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 720 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 sets per month |
| Product Name: | Solenoid Valve Timer | Series: | 720 |
|---|---|---|---|
| Theory: | Countdown | Usage: | Timer Switch |
| Protection Class: | IP65 | Inrush Current: | 10A For 10ms |
| Duty Cycle: | 100%ED | Time ON: | From 0.5 To 10s |
| Time OFF: | From 0.5 To 45 Min | Indicators: | Yellow LED |
| Manual Override: | Test | Termination: | DIN 43650 Form A |
| High Light: | Air Compressor Valve Electronic Cyclic Timer,Auto Drain Valve Digital Cyclic Timer,DIN43650 Form A Timer |
||
Air Compressor Auto Drain Valve Electronic Digital Cyclic Timer
Solid State cyclic, single shot and delay timers are used for simple automated ON/OFF control for solenoid valves, typically they fit directly between the solenoid valve coil and electrical DIN connector and come with a range either adjustable Time ON (Solenoid Valve Energised) and Time OFF (Solenoid Valve De Energised) or fixed timing cycles or schedules according to specific customer needs.
Typical Cyclic timers will provide LED Power ON and LED Power OFF indication, Manual Test button and most quality solid state cyclic timers will individually handle a voltage range from 24 volts to 250 volts with a current through put to the solenoid valve of up to 10 Amps.
Attention also needs to be focused on the Solenoid Valve coil / DIN Connector type and orientation. Obviously as these solid state cyclic timers fit between the coil and electrical connector they need to be the same DIN 43650 standard.
Repeat cycle timers, single shot timers and delay shot timers are supplied with either ISO 43650A form A and ISO 43650B form B fitment that typically fit directly between the solenoid valve coil and electrical Din connector without the need for additional time consuming wiring or cost of fitting.
Technical Data of Solenoid Valve Timer:
|
Supply voltage
|
24..240V AC/DC-50Hz/60Hz
|
|
Absorption current
|
4mA Max
|
|
Operating temperature
|
-10℃ to +50℃
|
|
Class protection
|
IP65-EN 60529
|
|
Switch holding voltage
|
400V Max
|
|
Switch capacity
|
1A
|
|
Inrush current
|
10A for 10ms
|
|
Duty cycle
|
100%ED
|
|
Switch life
|
3x10^8
|
|
Time ON
|
from 0.5 to 10s
|
|
Time OFF
|
from 0.5 to 45min
|
|
Indicators
|
Yellow LED
|
|
Manual override
|
Test
|
|
Termination
|
DIN43650A
|
Main Dimension of Solenoid Valve Timer:
Installation of Solenoid Valve Timer:
More Timer Controlled Solenoid Valves for you to choose:
Applications
1. Sampling gas or Liquids
2. Air dryers
3. Effluent sampling
4. Sprinkler systems
Technical Specification
1. Auto drain valve: automatic discharge of condensate
2. Pneumatic vibration systems (e.g. Powder silos)
3. Automatic lubrication systems
4. Dosing systems
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
