| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | LDF |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Refrigeration Solenoid Valve | Orifice Size: | 2mm, 3mm, 4mm, 5.8mm, 8mm |
|---|---|---|---|
| Tube OD (inch): | 1/4'', 5/16'', 3/8'' | Normal Position: | NC (Normally Closed) |
| Actuation: | Direct Acting, Pilot Operated | Max Operating Pressure: | 4.5 MPa |
| Wiring Type: | Flying Leads | Voltages: | 24VAC, 110VAC, 220VAC |
| Application: | Air Conditioner, Heat Pump, Ice Maker, Freezer, Cooler, Etc | ||
| High Light: | Refrigeration Solenoid Valve 5/16'',Sanhua Refrigeration Solenoid Valve 220V,Sanhua LDF Solenoid Valve |
||
Sanhua Type LDF Series Refrigeration Solenoid Valve For Air Conditioner 24V 110V 220V
LDF series solenoid valves are direct operated or pilot operated solenoid valves, mainly used in refrigerant control of various devices such as refrigerating and freezing systems, air conditioners and heat pumps.
* Applicable for all common HCFC, HFC refrigerants such as: R22, R134a, R404A, R407C, R410A, R507, R407A/F, R448A/R449A, R452A, R450A/R513A)
* Applicable medium temperature: -30ºC to +120ºC;
* Applicable ambient temperature: -30ºC to +50ºC;
* Relative humidity: below 95%
* Installation position:
1. Liquid, suction and discharge line
2. Coil upwards, coil axis ± 15º tolerance versus vertical axis
3. Flow direction corresponds to the arrow
Technical Data of LDF Series Solenoid Valve:
 |
| LDF2A |
|
| LDF8A |
| Model No | Function | Operation |
Orifice Size (mm) |
Kv Value (m³/h) |
MOP (MPa) |
Max OPD (MPa) |
Min OPD (MPa) |
Port Size (inch) |
| LDF2A01 | 2 Way Normally Closed | Direct | 2 | 0.12 | 4.5 | 3.1 | 0 | 1/4'' |
| LDF2A02 | 2 | 0.12 | 4.5 | 3.1 | 0 | 1/4'' | ||
| LDF3A08 | 3 | 0.26 | 4.5 | 3.1 | 0.005 | 1/4'' | ||
| LDF4A08 | 4 | 0.3 | 4.5 | 3.1 | 0.005 | 1/4'' | ||
| LDF6A08 | 5.8 | 0.6 | 4.5 | 3.1 | 0.005 | 5/16'' | ||
| LDF8A01 | 8 | 0.9 | 4.5 | 3.1 | 0.005 | 3/8'' | ||
| LDF8A02 | 8 | 1.1 | 4.5 | 3.1 | 0.005 | 3/8'' |
More Refrigeration Products for you to choose:
|
|
|
| Refrigeration Solenoid Valve | Expansion Valve | Refrigeration Ball Valve |
|
|
|
| Hot Gas Bypass Valve | Crankcase Pressure Regulator | 4 Way Reversing Valve |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Echo
Tel: +8613454729544
