| Place of Origin: | China, Ningbo |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 6213 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 50000 pcs per month |
| Port Size: | 1/4'', 3/8'', 1/2'', 3/4'', 1'' | Orifice Size: | 10mm, 13mm, 20mm, 25mm |
|---|---|---|---|
| Function: | 2 Way, Normally Closed | Operation: | Servo-Assisted Diaphragm |
| Body Material: | Stainless Steel | Diaphragm Material: | NBR, EPDM, FKM |
| Pressure Range: | 0.3 To 16 Bar | Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | Solenoid Valve 6213 A 3/8,Solenoid Valve 6213 A 3/4,Stainless Steel Solenoid Valve 6213 |
||
Stainless Steel Solenoid Valve 6213 A 3/8 1/2 3/4 10.0 13.0 20.0 25.0 NBR EPDM FKM
6213 is a servo-assisted diaphragm solenoid valve. The diaphragm spring coupling supports the opening process of the valve. In its standard version, the valve is suitable for use in liquids. A minimum differential pressure is required for complete opening. Various diaphragm material combinations are available depending on the application. The range of housings includes brass and stainless steel. The coils are moulded with polyamide or with chemically resistant epoxy.
Technical Data of 6213 Solenoid Valve:
|
Model
|
Orifice Size
(mm)
|
Port Size
(Inch)
|
Working Pressure
(bar)
|
Medium Temperature
(℃)
|
Body Material
|
Dimension
|
||
|
A
|
F
|
K
|
||||||
|
6213
|
10
|
1/4''
|
0.3 to 10
|
NBR: -10 to +80
EPDM: -30 to +120
FKM: -30 to +150
|
Brass
Stainless Steel
|
50
|
32
|
90/85
|
|
10
|
3/8''
|
50
|
32
|
90/85
|
||||
|
13
|
3/8''
|
65
|
41
|
91
|
||||
|
10
|
1/2''
|
50/55
|
32
|
90
|
||||
|
13
|
1/2''
|
58/65
|
41
|
91
|
||||
|
13
|
3/4''
|
58/69
|
41
|
94
|
||||
|
20
|
3/4''
|
83
|
60
|
115
|
||||
|
20
|
1''
|
83
|
60
|
115
|
||||
|
25
|
1''
|
83
|
60
|
115
|
||||
BRANDO Solenoid Valve Production Video:
