Name: 5/8'' SAE SV13A Fengshen Type Refrigeration Solenoid Valve 24VDC 220VAC
Brand: BRANDO
SKU: SV13A
Rating: 4.9 (125 reviews)

Home Products Refrigeration Solenoid Valve

5/8'' SAE SV13A Fengshen Type Refrigeration Solenoid Valve 24VDC 220VAC

Product Details:

Place of Origin:	China, Ningbo
Brand Name:	BRANDO
Certification:	CE, ISO
Model Number:	SV13A

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Box, Carton, Pallet
Delivery Time:	4 to 7 working days
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	20000 pcs per month

Contact Now

Detailed Product Description

Product Name:	Refrigeration Solenoid Valve	Port Size:	5/8''
Connection:	Flare (SAE)	Function:	2 Way Normally Closed
Refrigerant:	R134a, R22, R407C, R404A/507, Etc	Working Pressure Range:	0.005 To 2.1 MPa
Operation:	Diaphragm Pilot Operated	Voltage:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC, 380VAC
High Light:	Refrigeration Solenoid Valve 5/8'' , Refrigeration Solenoid Valve 24VDC , Fengshen SV13A

5/8'' SAE SV13A Fengshen Type Refrigeration Solenoid Valve 24VDC 220VAC

SV series solenoid valves for refrigeration, freezing and air conditioning plant applications in liquid, suction, and hot gas lines with refrigerants.

Options for you:

1. Connection Type: Flare (SAE), Solder (ODF);
2. Port Size: 1/4'', 3/8'', 1/2'', 5/8'', 3/4'' , 7/8'', 1-1/8'', 1-3/8'', 1-5/8'';
3. Operation: Direct Acting, Diaphragm Pilot Operated;
4. Coil Type: Best-NO.0210
5. Coil Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC, 380VAC.

Ordering Code of SV Series Refrigeration Solenoid Valves:

5/8'' SAE SV13A Fengshen Type Refrigeration Solenoid Valve 24VDC 220VAC 0

Specifications of SV Series Refrigeration Solenoid Valves:

Model	Connection Size (inch)	Connection Type	Kv (m³/h)	Operating Pressure (MPa)			Dimension (mm)
				Min	Max		Length	Wide	Height
				Min	AC	DC	Length	Wide	Height
SV1.6	1/4''	Flare (SAE)	0.15	0	3	2.6	48	33	55
SV2	1/4''		0.16		3	2.6	70	30	75
SV3	1/4''		0.23		2.1	1.7	70	30	75
SV6	5/16''		0.4	0.005	2.1	1.7	85	45	97
SV8	3/8''		1				85	45	97
SV10A	1/2''		1.8				85	45	97
SV13A	5/8''		3				89	45	97
SV16	3/4''		4.5				118	60	120
SV19	7/8''		5				118	60	120
SV1.6W	1/4''	Solder (ODF)	0.15	0	3	2.6	80	33	55
SV2W	1/4''		0.16		3	2.6	118	30	75
SV3W	1/4''		0.23		2.1	1.7	118	30	75
SV6W	5/16''		0.4	0.005	2.1	1.7	126	45	97
SV8W	3/8''		1				126	45	97
SV10AW	1/2''		1.8				126	45	97
SV13AW	5/8''		3				150	45	97
SV16W	3/4''		4.5				190	60	120
SV19W	7/8''		5				190	60	120
SV25W	1 1/8''		9.5	0.03			240	72	120
SV25W	1 3/8''		9.5				250	72	120
SV32W	1 3/8''		15				260	86	130
SV32W	1 5/8''		15				281	86	130
