Name: 1/2'' 2 Way NC High Temp Stainless Steel Solenoid Valve PTFE Seal
Brand: Brando
SKU: SUS-15
Rating: 4.5 (182 reviews)

Home Products Stainless Steel Solenoid Valve

1/2'' 2 Way NC High Temp Stainless Steel Solenoid Valve PTFE Seal

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	SUS-15

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	300000 sets per month

Contact Now

Detailed Product Description

Port Size:	1/2''	Orifice Size:	15mm
Function:	2 Way, Normally Closed	Operation:	Piston Pilot Operated
Body Material:	Stainless Steel	Seal Material:	PTFE
Voltages:	24VDC, 110VAC, 220VAC	Working Pressure Range:	0.05 To 6 MPa
High Light:	1/2'' Stainless Steel Solenoid Valve , 2 Way NC Stainless Steel Solenoid Valve , SUS-15 Solenoid Valve

1/2'' 2 Way NC High Temp Stainless Steel Solenoid Valve PTFE Seal

We supply a wide range of 2 and 3 way, high quality, general-purpose stainless steel solenoid valves which are used in demanding applications around the world. These robust all stainless steel solenoid valves can be used in many industrial, medical and scientific applications to control a wide variety of fluids that are compatible with the materials of construction.

1. All stainless steel construction – suitable for controlling most industrial fluids including pure water, aggressive media, steam, oxygen, vacuum, air and many gases.
2. Wide range - we offer both 2 way and 3 way stainless solenoid valves with normally closed or normally open operation from a single source.
3. 2/2 and 3/2 ss solenoid valves – Easy availability.

4. 1/8'' to 3'' sizes – Size to suit application.
5. Available in both AC and DC operation – Simplifies electrical circuitry.
6. NBR, FKM, PTFE & EPDM seal material for optional – for maximum compatibility with many common and agressive industrial fluids.

Main Dimension of SUS series Stainless Steel Solenoid Valve:

1/2'' 2 Way NC High Temp Stainless Steel Solenoid Valve PTFE Seal 0

Model	L	H	A	B	φC	D	K
SUS-15	69	121	14	48.5	48	83.5	1/2''
SUS-15-NO		128
SUS-20	79	133	18	55.5			3/4''
SUS-20-NO		140
SUS-25	96	142	21	70			1''
SUS-25-NO		149
SUS-32	109	152	27	70			1 1/4''
SUS-32-NO		159
SUS-40	128	167	31	95			1 1/2''
SUS-40-NO		174
SUS-50	150	183	38	100			2''
SUS-50-NO		190

Technical Data of SUS Series Stainless Steel Solenoid Valve:

Model	SUS-15	SUS-20	SUS-25	SUS-32	SUS-40	SUS-50
Model	SUS-15-NO	SUS-20-NO	SUS-25-NO	SIUS-32-NO	SUS-40-NO	SUS-50-NO
Port Size	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	15mm	20mm	25mm	32mm	40mm	50mm
Cv Value	5	6	13	20	28	39.5
Function	2 way, normally closed / normally open
Operation	Piston pilot operated
Body Material	Stainless steel 304
Seal Material	PTFE, FKM, EPDM
Working Temperature	PTFE: -20 to +180℃, FKM: -10 to +150℃, EPDM: -5 to +120℃
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Protection Class	IP65, IP67, Ex-proof
Insulation Class	F, H
Installation	Horizontal or Slant
