| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 2S160-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Valve Series: | 2S Series | Ref. Number: | UNI-D Type SUW-15 |
|---|---|---|---|
| Voltage: | AC110V AV220V DC24V | Action: | Pilot Diaphragm |
| Port Size: | 1/2'' Inch | Media: | Water Air Gas |
| Fluid Viscossity: | Below 20 CST | Power: | Solenoid |
| Body Material: | Stainless Steel | Diaphragm Material: | NBR, FKM And EPDM |
| Highlight: | 2S160-15 Stainless Steel Solenoid Valve,G1/2'' Stainless Steel Solenoid Valve,UNI-D SUW-15 |
||
2S160-15 G1/2'' Stainless Steel Solenoid Valve For Water Air
2S160-15
2S: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.
160: The Aperture of Flow Rate is 16 mm
15:Joint Pipe Bore is G1/2 Inch Female Thread
Technical Data of 2W & 2S Solenoid Valve:
|
2W Series
|
2W025-08
|
2W040-10
|
2W160-15
|
2W200-20
|
2W250-25
|
2W350-35
|
2W400-40
|
2W500-50
|
|
2S Series
|
2S025-08
|
2S040-10
|
2S160-15
|
2S200-20
|
2S250-25
|
2S350-35
|
2S400-40
|
2S500-50
|
|
Orifice Size
|
2.5
|
4
|
15
|
20
|
25
|
35
|
40
|
50
|
|
Port Size
|
1/4''
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Medium
|
Water, Air, Gas, Oil
|
|||||||
|
Action
|
Direct Acting
|
Semi-Direct Diaphragm Operated
|
||||||
|
Function
|
2 Way, Normally Closed
|
|||||||
|
Fluid Viscosity
|
20 CST below
|
|||||||
|
Pressure
Range
|
0 to 1.0 Mpa
|
|||||||
|
Temp. Range
|
-5 to +85℃
|
|||||||
Main dimension of 2W & 2S Series Solenoid Valves:
|
2S Series
|
2W Series
|
A
|
B
|
C
|
D
|
E
|
|
2S025-06
|
2W025-06
|
64.5
|
30
|
75
|
43
|
1/8''
|
|
2S025-08
|
2W025-08
|
64.5
|
30
|
75
|
43
|
1/4''
|
|
2S040-10
|
2W040-10
|
70.6
|
32
|
82.4
|
53
|
3/8''
|
|
2S160-10
|
2W160-10
|
101.5
|
57
|
117
|
69
|
3/8''
|
|
2S160-15
|
2W160-15
|
101.5
|
57
|
117
|
69
|
1/2''
|
|
2S200-20
|
2W200-20
|
107
|
57
|
123.5
|
73
|
3/4''
|
|
2S250-25
|
2W250-25
|
111.5
|
73.5
|
134.5
|
99
|
1''
|
|
2S350-35
|
2W350-35
|
142
|
95
|
172
|
123
|
1-1/4''
|
|
2S400-40
|
2W400-40
|
142
|
95
|
172
|
123
|
1-1/2''
|
|
2S500-50
|
2W500-50
|
172
|
123
|
209
|
168
|
2''
|
The difference between Normally Close and Normally Open Solenoid Valve
Normally open solenoid valve
Normally open solenoid valve is closed when the solenoid coil is powered, and the normally closed solenoid valve is open when the solenoid coil is off. If the solenoid valve is required long-term opening, the normally open solenoid valve will be the ideal choice. If the solenoid valve is required long-term opening or close, the bistable solenoid valve is more suitable. As for the voltage, AC (380V, 240V, 220V, 24V) and DC (110V, 24V) is applicable for the normally open solenoid valve.
Normally open solenoid valve applies to the actuator that using steam as heat medium and automatically control temperature. normally open solenoid valve can make two-position automatic control and remote control to the steam heater, radiator, dryer and other steaming plants. Normally open solenoid valve has wide applications, including dyeing, textile, printing and dyeing, food, medicine, tobacco, cement product, petrochemical industry, metallurgy and etc.
Normally closed solenoid valve
Normally closed solenoid valve means closed when the solenoid coil is powered, and the solenoid valve is open when the solenoid coil is off. Normally closed solenoid valve apply for international standard voltage include AC 380V, 240v, 220v, 24v or DC 110V, 24V.
