2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature
video
2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPO213044278
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Position And Way: 2 Way 2 Position Non-working Status: Normally Open
Voltage: AC, DC All Available Plunger Tube OD: φ13.0mm
Seat Type: M16 Thread Plunger Tube Material: Stainless Steel 304
High Light:

2/2 Way Solenoid Valve Armature

,

Normally Opened Solenoid Valve Armature

,

NO Plunger Assembly

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature



The solenoid consists of a coil of wire wound in the form of a cylinder around the bobbin. When an electrical current is introduced, it resembles a bar magnet. When energized by an electrical signal, a magnetic field builds up which attracts the movable plunger to the polepiece against the tension of the main plunger spring. When de-energized, the magnetic field dissipates and the plunger returns to its original position, under the action of the main plunger spring.



In order to be usable on AC current as well as DC, the polepiece contains a shading ring to average the alternating sine wave and minimize AC hum. (Note - It is not necessary to use a shading ring for DC applications as DC current does not produce an alternating wave function.) The flowing media is normally permitted to enter the area between the plunger and plunger guide tube, and caution should be used to assure that these components are compatible with the media when selecting a valve.



Main dimension of Solenoid Valve Armature Assembly:

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature 0



Details of Solenoid Valve Armature Assembly:

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature 1

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature 2



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPO213044278
Guide Tube Outer Diameter
13.0mm
Installation Height for Coil Assembling
46.5mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
M25 Thread
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Open
Customized Service
Provided, welcome show us sample or drawing


Brando Factory Production of Solenoid Valve Armature Assembly:

2/2 Way Normally Opened 13mm OD Flow Control Solenoid Valve Armature 3



More Solenoid Valve Armature Assembly for you to choose:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)

FAQ:



How can you tell if your solenoid is bad?
If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.



What is a solenoid?
A solenoid is an electric coil that is wrapped around a ferromagnetic substance (such as iron) that acts as an electromagnet when the current is passed through it.



How does a solenoid work?
When the electric current is passed through the coil, an electromagnetic field is created. This electromagnetic field causes the plunger to move up or down. This mechanism is used by solenoid valves to open or close the valve.
