B297DVEN D618282 Flow Control Solenoid Valve Armature Assembly

B297DVEN D618282 Flow Control Solenoid Valve Armature Assembly

This is a set of solenoid valve armature assembly, including 1 x stainless steel armature tube, 1 x plunger with NBR seal and 1 x spring. This armature assembly is designed for 3 way normally closed solenoid valves. The plunger tube outer diameter is 10mm, so it is suitable to 10mm inner hole diamter solenoid coil. The standard plunger's seal material is NBR, but HNBR, VITON, EPDM, Silicone are all available to customize.

Technical data of Solenoid Valve Armature Assembly:

Main dimension of Solenoid Valve Armature Assembly:

Details of Solenoid Valve Armature Assembly:

3 Way, Copper Shading Ring                         Thread Seat

                Plunger Slot                                NBR Seal

Brando Factory Production of Solenoid Valve Armature Assembly:

More Solenoid Valve Armature Assembly for you to choose:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

*According to tube material: Brass, Stainless Steel

*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

Function Type

2/2 way function indicates valves with inlet and outlet connections, whilst valves with 3/2 way functions have 3 connections and 2 flow passages. One orifice always remains open and one closed. Connections and flow direction are shown in the symbols on each technical data sheet (DIN-ISO 1219). At rest valves can be either normally closed (NC) or normally open (NO): - Normally closed (NC): the valve opens when the coil is energised. - Normally open (NO): the valve closes when the coil is energised.
