| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | BAPC308023010 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union,Paypal, MoneyGram |
| Supply Ability: | 300000 sets per month |
| Function: | 3 Way, Normally Closed | Seat Type: | Flange |
|---|---|---|---|
| Plunger Tube Material: | Brass | Plunger Tube OD: | φ8mm |
| Seal Material: | NBR | Voltage: | AC, DC All Available |
| Application: | 4V100 Series Pneumatic Solenoid Valve | Valve Model: | 4V110-06, 4V120-06, 4V130C-06 |
| High Light: | Pneumatic Solenoid Valve,S8 Armature Plunger,AMISCO Type S8 |
||
S8 Pneumatic Solenoid Valve 3 Way NC 8mm Hole Armature Plunger
How to choose a right solenoid armature?
During the choose of the Solenoid Armature, you should pay attention to below factors:
1. Working voltage: AC or DC
2. Switching function: 2/2 or 3/2way;
3. De-energized state: Normal close, normal open or Divert
4. Stroke of the matched valve body
5. Valve’s orifice
6. Working environment: working medium, temperature, pressure of pipeline etc
How does an armature assembly work?
When the working current passing through the coil, a magnetic field is generated around the coil. The electromagnetic force drives the moving iron core to overcome the resistance of the spring to move upward, and it is absorbed with the static iron core.
When the coil is powered off, the electromagnetic force disappears, and the moving iron core is reset downward under the action of the spring force.
Details of Solenoid Valve Armature Assembly:
3 Way Normally Closed Flange Seat
Plunger Slot NBR Seal
Technical data of Solenoid Valve Armature Assembly:
Main dimension of Solenoid Valve Armature Assembly:
Brando Factory Production of Solenoid Valve Armature Assembly:
More Solenoid Valve Armature Assembly for you to choose:
*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.
*According to tube material: Brass, Stainless Steel
*According to valve application:
1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
