6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature
video
6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC306022801
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Function: 3 Way, Normally Closed Seat Type: Flange
Plunger Tube Material: Stainless Steel Plunger Tube OD: φ6.3mm
Seal Material: VITON (FKM) Voltage: AC, DC All Available
High Light:

6mm OD Solenoid Valve Armature

,

Medical Solenoid Valve Armature

,

Oxygen Conserver Material Part

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature



The magnetic (solenoid) valve includes an electromagnet which comprises a coil arrangement and an armature driven by the coil arrangement. A control part is provided on the armature, which corresponds to at least one channel aperture to be controlled in a fluid channel, and which is shifted at the control movement of the armature relative to the at least one channel aperture. The armature is formed as a pivot anchor, whose switching movement is a pivotal movement , at which the control part is shifted orthogonally to the longitudinal axis of the coil arrangement.



The main characteristics of the armature of solenoid valve can be reflected in the following aspects.



1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive;

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer;

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance;

4. Sealing materials can be selected according to your different requirements;

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection.


Main dimension of Solenoid Valve Armature Assembly:

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature 0

Details of Solenoid Valve Armature Assembly:

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature 1

  3 Way Normally Closed              Plunger Slot                             VITON Seal



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPC306022801
Guide Tube Outer Diameter
6.3mm
Installation Height for Coil Assembling
19.3mm
Plunger Seal for Orifice Diameter
3.2mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing

Brando Factory Production of Solenoid Valve Armature Assembly:

6mm OD 3/2 Way Medical Oxygen Conserver Solenoid Valve Armature 2



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)



Product Features of Solenoid Valve Armature Assembly:


1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.



2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.



3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.



4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.



5 Shading ring:
Cooper and silver material available.



6. Washer and retaining nut provided if has demands.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
