| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 2S025-08 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Valve Series: | 2S Series | Ref. Number: | UNI-D Type SUS-08 |
|---|---|---|---|
| Voltage: | AC110V AV220V DC24V | Action: | Direct Acting |
| Port Size: | 1/4'' | Media: | Water Air Gas |
| Fluid Viscossity: | Below 20 CST | Power: | Solenoid |
| Body Material: | Stainless Steel | Diaphragm Material: | NBR, FKM And EPDM |
| High Light: | 1/4 Inch Stainless Steel Solenoid Valve,SUS-8 Stainless Steel Solenoid Valve,Uni-D Type SUS-08 |
||
1/4 Inch Mini 2S025-08 SUS-8 Water Stainless Steel Solenoid Valve
This is a 2W025-08 mini solenoid valve, 1/4 inch (G, NPT) female thread port size, stainless steel 304 body material, NBR seal material, 2 way normally closed, direct acting, 12V DC, 24V DC, 110V AC, 120V AC, 220V AC, 230V AC voltages for you to choose, other voltages can be customized.
2S series stainless steel solenoid valve: 2S025-06, 2S025-08, 2S040-10, 2S160-10, 2S160-15, 2S200-20, 2S250-25, 2S350-35, 2S400-40, 2S500-50.
2W series brass solenoid valve: 2W025-06, 2W025-08, 2W040-10, 2W160-10, 2W160-15, 2W200-20, 2W250-25, 2W350-35, 2W400-40, 2W500-50.
2S025-08
2S: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.
025: The Aperture of Flow Rate is 2.5 mm
08:Joint Pipe Bore is G1/4 Inch Female Thread
Technical Data of 2W & 2S Solenoid Valve:
|
2W Series
|
2W025-08
|
2W040-10
|
2W160-15
|
2W200-20
|
2W250-25
|
2W350-35
|
2W400-40
|
2W500-50
|
|
2S Series
|
2S025-08
|
2S040-10
|
2S160-15
|
2S200-20
|
2S250-25
|
2S350-35
|
2S400-40
|
2S500-50
|
|
Orifice Size
|
2.5
|
4
|
15
|
20
|
25
|
35
|
40
|
50
|
|
Port Size
|
1/4''
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Medium
|
Water, Air, Gas, Oil
|
|||||||
|
Action
|
Direct Acting
|
Semi-Direct Diaphragm Operated
|
||||||
|
Function
|
2 Way, Normally Closed
|
|||||||
|
Fluid Viscosity
|
20 CST below
|
|||||||
|
Pressure
Range
|
0 to 1.0 Mpa
|
|||||||
|
Temp. Range
|
-5 to +85℃
|
|||||||
Main dimension of 2W & 2S Series Solenoid Valves:
|
2S Series
|
2W Series
|
A
|
B
|
C
|
D
|
E
|
|
2S025-06
|
2W025-06
|
64.5
|
30
|
75
|
43
|
1/8''
|
|
2S025-08
|
2W025-08
|
64.5
|
30
|
75
|
43
|
1/4''
|
|
2S040-10
|
2W040-10
|
70.6
|
32
|
82.4
|
53
|
3/8''
|
|
2S160-10
|
2W160-10
|
101.5
|
57
|
117
|
69
|
3/8''
|
|
2S160-15
|
2W160-15
|
101.5
|
57
|
117
|
69
|
1/2''
|
|
2S200-20
|
2W200-20
|
107
|
57
|
123.5
|
73
|
3/4''
|
|
2S250-25
|
2W250-25
|
111.5
|
73.5
|
134.5
|
99
|
1''
|
|
2S350-35
|
2W350-35
|
142
|
95
|
172
|
123
|
1-1/4''
|
|
2S400-40
|
2W400-40
|
142
|
95
|
172
|
123
|
1-1/2''
|
|
2S500-50
|
2W500-50
|
172
|
123
|
209
|
168
|
2''
|
Features:
1.Direct-Acting, conductive, normally closed.
2.Valve body material is Stainless steel.
3.Can be operated directly without pressure.
4.Small size and easy assembly.
5.Standard voltage : 24VDC,110VAC, 220VAC AC Voltage tolerance: ± 10% ,
DC Voltage tolerance:±1%.
6.Other special AC/DC can be made to client's order.
7.Thread: BSPT, NPT , BSP.
8.The standard product fluid temperature is 80°C(NBR).
9.Temperature:Viton(130°C), Silicon(130°C), PTFE(185°C).
10. DIN43650A connector Coil is interchangeable
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
