| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | EVR3-038S |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Type: | Direct Acting | Body Material: | Brass |
|---|---|---|---|
| Port Size: | 3/8'' | Function: | Normally Closed |
| Coil: | No | Inlet & Outlet Connection Type: | ODF Solder |
| Applcation: | Refrigeration Part | CV/KV: | 0.31 /0.27 |
| Highlight: | 032F1213 Cooling Solenoid Valve,032F1212 Cooling Solenoid Valve,Danfoss Type 032L1213 032L7116 |
||
032F1213 032F1212 EVR 6 NC 3/8'' 10mm Solder ODF Cooling Solenoid Valve
032F1204 EVR3-038S s Type Solder ODF Connection 3/8'' Solenoid Valve For Refrigeration Without Coil
This type is s type EVR3 series port size 3/8'' Refrigeration Valve for air conditioning. EVR is a direct or servo-Operated solenoid valve, using for fluid, suction and heat pipe with fluorinated refrigerants. EVR is available either as a single valve or the like separate components.
Direct Acting Valve:
The direct acting solenoid valve is usually used in small caliber and low pressure environment.it will be able to start in zero pressure, without need of the minimum pressure of the medium. It is simple to control and has a wide application scope.
Pilot Operated Valve
The pilot-operated solenoid valve is usually used in big diameter and high pressure occasions.the pilot pressure is required, otherwise it cannot be opened. In addition, the flow capability of the pilot-operated solenoid valve is bigger than that of the direct acting solenoid valve.
Dimension:
Data Sheet Of EVR Series:
|
Type
|
Connection size (inch)
|
Connection size
(mm)
|
Max. working Pressure
(bar)
|
Kv value
(m3/h)
|
Code NO.
|
|
EVR 2
|
1/4
|
-
|
45.2
|
0.15
|
032F1201
|
|
-
|
6
|
45.2
|
0.15
|
032F1202
|
|
|
EVR 3
|
1/4
|
-
|
45.2
|
0.26
|
032F1206
|
|
3/8
|
-
|
45.2
|
0.26
|
032F1204
|
|
|
-
|
6
|
45.2
|
0.26
|
032F1207
|
|
|
-
|
10
|
45.2
|
0.26
|
032F1208
|
|
|
EVR 6
|
1/2
|
-
|
45.2
|
0.80
|
032L1209
|
|
3/8
|
-
|
45.2
|
0.80
|
032L1212
|
|
|
-
|
10
|
45.2
|
0.80
|
032L1213
|
|
|
-
|
12
|
45.2
|
0.80
|
032L1236
|
|
|
EVR 10
|
1/2
|
-
|
35
|
1.9
|
032L1217
|
|
-
|
12
|
35
|
1.9
|
032L1218
|
|
|
5/8
|
16
|
35
|
1.9
|
032L1214
|
|
|
EVR 15
|
7/8
|
22
|
32
|
2.6
|
032L1225
|
|
5/8
|
16
|
32
|
2.6
|
032L1228
|
|
|
EVR 20
|
7/8
|
22
|
32
|
5.0
|
032L1240
|
|
1 1/8
|
-
|
32
|
5.0
|
032L1244
|
|
|
-
|
28
|
32
|
5.0
|
032L1245
|
|
|
7/8
|
22
|
32
|
5.0
|
032L1264
|
|
|
EVR 22
|
1 3/8
|
35
|
32
|
6.0
|
032L3267
|
|
EVR 25
|
1 1/8
|
-
|
32
|
10.0
|
032L2201
|
|
-
|
28
|
32
|
10.0
|
032L2206
|
|
|
1 3/8
|
-
|
32
|
10.0
|
032L2207
|
|
|
1 3/8
|
-
|
32
|
10.0
|
032L2208
|
|
|
EVR 32
|
1 5/8
|
-
|
32
|
10.0
|
042L1104
|
|
-
|
35
|
32
|
16.0
|
042L1105
|
|
|
-
|
35
|
32
|
16.0
|
042L1106
|
|
|
-
|
42
|
32
|
32
|
042L1108
|
|
|
EVR 40
|
1 5/8
|
-
|
32
|
32
|
042L1110
|
|
2 1/8
|
-
|
32
|
32
|
042L1112
|
|
|
|
42
|
32
|
32
|
042L1114
|
Feature:
Complete range of solenoid valves for refrigeration, freezing and air conditioning plant
Supplied in versions normally closed (NC) and normally open (NO) with de-energized coil
Wide choice of coils for a.c. and d.c.
Suitable for all fluorinated refrigerants,including flammable refrigerants
Designed for media temperatures up to 105 °C
MOPD up to 25 bar with 12 W coil
Flare connections up to 5/8 in.
Solder connections up to 2 1/8 in.
Extended ends on solder versions make the installation easy. It is not necessary to dismantle the valve when soldering in.
Available in flare, solder and flange conection versions
