| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | 8CA2S |
| Minimum Order Quantity: | 4pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 7 working days |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 5000pcs per month |
| Product Name: | High Pressure Solenoid Valve | Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' |
|---|---|---|---|
| Orifice Size: | 1mm, 1.2mm, 1.5mm, 2mm, 2.5mm, 3mm | Body Material: | Stainless Steel 304 |
| Seal Material: | PTFE | Working Media: | Water, Air, Gas, Liquid, Etc |
| Working Media Temperature: | -60 To +200℃ | Max Pressure: | 140 Bar |
| Operation: | Direct Operated | Function: | 2/2 Way Normally Closed |
| Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | ||
| High Light: | High Pressure Solenoid Valve 140 bar,Stainless Steel High Pressure Solenoid Valve,High Pressure Solenoid Valve 24V |
||
140 bar Stainless Steel High Pressure Solenoid Valve For Water Air 24V 110V 220V
Product Features:
1. Working Media: Water, Air, Gas, Liquid, etc
2. Working Pressure: 0 to 140 bar
3. Media Temperature: -60 to +200℃
4. Port Size: 1/8'', 1/4'', 3/8'', 1/2''
5. Orifice Size: 1mm, 1.2mm, 1.5mm, 2mm, 2.5mm, 3mm
6. Body Material: Stainless Steel 304
7. Seal Material: PTFE
8. Function: 2 Way Normally Closed
9. Operation: Direct Acting
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Technical Data:
|
Model No
|
Port Size
|
Orifice Size
|
Cv
|
Min Pressure
|
Max Pressure
|
Body
|
Seal
|
Voltage
|
|
|
AC
|
DC
|
||||||||
|
8CA2S010BXX
|
1/8''
1/4'' 3/8'' 1/2''
|
1mm
|
0.09
|
0 bar
|
130 bar
|
140 bar
|
SS304
|
PTFE
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
8CA2S012BXX
|
1.2mm
|
0.1
|
0 bar
|
120 bar
|
130 bar
|
||||
|
8CA2S015BXX
|
1.5mm
|
0.13
|
0 bar
|
110 bar
|
120 bar
|
||||
|
8CA2S020BXX
|
2mm
|
0.15
|
0 bar
|
90 bar
|
100 bar
|
||||
|
8CA2S025BXX
|
2.5mm
|
0.18
|
0 bar
|
30 bar
|
70 bar
|
||||
|
8CA2S030BXX
|
3mm
|
0.3
|
0 bar
|
22 bar
|
40 bar
|
||||
Main Dimension:
|
Model No
|
Port
|
A
|
B
|
C
|
D
|
E
|
|
8CA2SXXXB01
|
1/8''
|
40
|
27
|
82
|
10.5
|
82
|
|
8CA2SXXXB02
|
1/4''
|
40
|
27
|
82
|
10.5
|
82
|
|
8CA2SXXXB03
|
3/8''
|
46
|
27
|
82
|
13.5
|
82
|
|
8CA2SXXXB04
|
1/2''
|
50
|
27
|
82
|
13.5
|
82
|
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of
applications.
Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
