Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem
video
Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC316038825
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Position And Way: 3 Way 2 Position Non-working Status: Normally Closed
Voltage: AC, DC All Available Plunger Tube OD: φ16mm
Seat Type: M20 Thread Plunger Tube Material: Stainless Steel 304
Seal Material: PTFE
High Light:

Solenoid Valve Armature Stem

,

PTFE Seal Armature Stem

,

PTFE Seal Solenoid Plunger

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem



Solenoid Valve Armature Assembly Categories:



The armature assembly can usually be categorized according to the number of interface positions, switching functions and connection.



1. Port / positions: 2/2 way or 3/2 way (The first figure shows the number of ports, the second shows the number of positions)
2. Function: Normally closed (NC), or normally open (NO)
3. Connection: Thread or flange



Features of Armature Assembly:



The main characteristics of the armature of solenoid valve can be reflected in the following aspects.

1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection



Main dimension of Solenoid Valve Armature Assembly:

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem 0

Details of Solenoid Valve Armature Assembly:

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem 1

              3/2 Way NC                                   M20 Thread

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem 2

          Plunger Slot                                   PTFE Seal



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPC316038825
Guide Tube Outer Diameter
16.0mm
Installation Height for Coil Assembling
38.0mm
Plunger Seal for Orifice Diameter
6.8mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
M20 Thread
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing


Brando Factory Production of Solenoid Valve Armature Assembly:

Water Air Solenoid Valve 3/2 NC PTFE Seal Solenoid Armature Stem 3



More Solenoid Valve Armature Assembly for you to choose:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)

FAQ:



How can you tell if your solenoid is bad?
If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.



What is a solenoid?
A solenoid is an electric coil that is wrapped around a ferromagnetic substance (such as iron) that acts as an electromagnet when the current is passed through it.



How does a solenoid work?
When the electric current is passed through the coil, an electromagnetic field is created. This electromagnetic field causes the plunger to move up or down. This mechanism is used by solenoid valves to open or close the valve.
