3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem
video
3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC313054054
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Position And Way: 3 Way 2 Position Non-working Status: Normally Closed
Seat Type: M20 Thread Plunger Tube Material: Stainless Steel 304
Plunger Tube OD: φ13mm Seal Material: FKM (Viton)
Voltage: AC, DC All Available Application: Coffee Machine Solenoid Valve
High Light:

3 Way Armature Stem

,

Coffee Machine Solenoid Valve Armature Stem

,

Coffee Machine Solenoid Valve Spare Part

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem



Brando provides customized solenoid valve armature services for various types of solenoid valves.



Our solenoid valve armature assembly has high quality, precise stroke control, long service life, and a full range of products, including 3/2-way, 2/2-way, normally open, normally closed, and threaded or flanged connection available.



Our solenoid valve armatures are widely used in pneumatic, hydraulic, fluid control fields, covering textiles, home appliances, automobiles, refrigeration and other automation control industries.



Main dimension of Solenoid Valve Armature Assembly:

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem 0



Details of Solenoid Valve Armature Assembly:

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem 1

                 3/2 Way NC                                        Thread Seat

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem 2

             Plunger Slot                                    FKM Seal



Technical data of Solenoid Valve Armature Assembly:

Model Number
BAPC313054054
Guide Tube Outer Diameter
13.0mm
Installation Height for Coil Assembling
35.0mm
Plunger Seal for Orifice Diameter
6.3mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
M20 Thread
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Close
Customized Service
Provided, welcome show us sample or drawing


Brando Factory Production of Solenoid Valve Armature Assembly:

3 Way NC Coffee Machine Solenoid Valve Stainless Steel Armature Stem 3



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)



How to choose a right solenoid armature?



During the choose of the Solenoid Armature, you should pay attention to below factors:



1. Working voltage: AC or DC



2. Switching function: 2/2 or 3/2way;



3. De-energized state: Normal close, normal open or Divert



4. Stroke of the matched valve body



5. Valve’s orifice



6. Working environment: working medium, temperature, pressure of pipeline etc
