3 Way 13.0mm OD Stainless Steel Flow Control Solenoid Valve Armature

3 Way 13.0mm OD Stainless Steel Flow Control Solenoid Valve Armature

3 Way 13.0mm OD Stainless Steel Flow Control Solenoid Valve Armature
video
3 Way 13.0mm OD Stainless Steel Flow Control Solenoid Valve Armature
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC313042011
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Fittings Guide Tube Outer Diameter: 13.0mm
Installation Height For Coil Assembling: 40.2mm Plunger Seal For Orifice Diameter: 7.5mm
Guide Tube Material: Stainless Steel Seal Material: NBR
Mounting Type: Thread Voltage: AC, DC All Available
Position And Way: 3/2 Way Applicable: Solenoid Valve
High Light:

13.0mm OD Solenoid Valve Armature

,

Flow Control Solenoid Valve Armature

,

3 Way 13.0mm OD Plunger

3 Way 13.0mm OD Stainless Steel Flow Control Solenoid Valve Armature



Stainless steel (Stainless Steel) is the abbreviation of stainless and acid-resistant steel. It is called stainless steel that is resistant to weak corrosive media such as air, steam, and water, or is stainless steel; and chemically resistant to chemical corrosion media (acid, alkali, salt, etc.) Corrosion steel is called acid-resistant steel.
Due to the different uses of each product, the processing technology and the quality requirements of the raw materials are also different. Generally speaking, different stainless steel products require different thickness tolerances of raw materials. For example, the thickness tolerance of the second type tableware and the vacuum flask is generally higher, which is -3~5%, while the thickness tolerance of the first type tableware is generally required- 5%, steel pipe category requires -10%, hotel refrigerator material thickness tolerance is -8%, dealers generally require thickness tolerance between -4% and 6%. At the same time, the difference between the internal and external sales of products will also lead to the different requirements of customers on the thickness tolerance of the raw materials. Generally, customers of export products require relatively high thickness tolerances, while domestic sales companies have relatively low requirements for thickness tolerances (mostly due to cost considerations), and some customers even require -15%.



Brando provides customized solenoid armature services for various types of solenoid valves.

Our solenoid armature assembly has high quality, precise stroke control, long service life, and a full range of products, including 3/2-way, 2/2-way, normally open, normally closed, and threaded or flanged connection available.

Brando Solenoid plungers are available in numerous designs and have been tested to meet rigorous performance requirements for solenoid valves. These solenoid plungers can be utilized in various applications including, air and fluid power applications, heating and cooling system regulation units, industrial, and automotive applications.



Condition:New
Applicable Industries:Solenoid Valve
Type:Fittings
Place of Origin:Zhejiang, China
Brand Name:Brando
Guide Tube Outer Diameter:13.0mm
Installation Height for Coil Assembling:40.2mm
Plunger Seal for Orifice Diameter:7.5mm
Guide Tube Material:Stainless Steel
Seal Material:NBR
Mounting Type:Thread
Voltage:AC, DC All Available
Position and Way:3/2 Way
Non-working Status:Normally Close



Dimension of BAPC313042011 Armature Assembly:



Dimension of BAPC313042011 Armature Assembly:





Technical Data:

Model Number
BAPC313042011
Guide Tube Outer Diameter
13.0mm
Installation Height for Coil Assembling
40.2mm
Plunger Seal for Orifice Diameter
7.5mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
Thread
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing





Product Features:

1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut provided if has demands.



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)


Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any question and inquiry!
