19090005 19000006 19000008 CNOMO Size 30 Solenoid Valve Armature

19090005 19000006 19000008 CNOMO Size 30 Solenoid Valve Armature

19090005 19000006 19000008 CNOMO Size 30 Solenoid Valve Armature
video
19090005 19000006 19000008 CNOMO Size 30 Solenoid Valve Armature
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC310033814
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Fittings Guide Tube Outer Diameter: 10.0mm
Installation Height For Coil Assembling: 32.0mm Plunger Seal For Orifice Diameter: 4.2mm
Guide Tube Material: Brass Seal Material: NBR
Mounting Type: Flange Voltage: AC, DC All Available
Position And Way: 3/2 Way Applicable: Solenoid Valve
High Light:

19090005 Solenoid Valve Armature

,

19000008 Solenoid Valve Armature

,

18990001 18900001 18900073 Armature

19090005 19000006 19000008 CNOMO Size 30 Solenoid Valve Armature



There are four basic types of 3-way solenoid valves. Each of these different types is used for different purposes. Two of the main types include 3-way normally closed and 3-way normally open. These two valves vary simply by the fact that one has a normally open passageway, while the other has a normally closed one. If the 3-way valve is needed for more complex functions, either the 3-way directional control or the 3-way multipurpose valve can be used.



Brando provides customized solenoid armature services for various types of solenoid valves.

Our solenoid armature assembly has high quality, precise stroke control, long service life, and a full range of products, including 3/2-way, 2/2-way, normally open, normally closed, and threaded or flanged connection available.

Brando Solenoid plungers are available in numerous designs and have been tested to meet rigorous performance requirements for solenoid valves. These solenoid plungers can be utilized in various applications including, air and fluid power applications, heating and cooling system regulation units, industrial, and automotive applications.



Condition:New
Applicable Industries:Solenoid Valve
Type:Fittings
Place of Origin:Zhejiang, China
Brand Name:Brando
Guide Tube Outer Diameter:10.0mm
Installation Height for Coil Assembling:32.0mm
Plunger Seal for Orifice Diameter:4.2mm
Guide Tube Material:Brass
Seal Material:NBR
Mounting Type:Flange
Voltage:AC, DC All Available
Position and Way:3/2 Way
Non-working Status:Normally Close



Dimension of BAPC310033814 Armature Assembly:



Dimension of BAPC310033814 Armature Assembly:





Technical Data:

Model Number
BAPC310033814
Guide Tube Outer Diameter
10.0mm
Installation Height for Coil Assembling
32.0mm
Plunger Seal for Orifice Diameter
4.2mm
Guide Tube Material
Brass
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
Flange
Voltage
All range of AC and DC available
Position and Way
3/2 Way
Non-working Status
Normally Closed
Customized Service
Provided, welcome show us sample or drawing





Product Features:

1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut provided if has demands.



More Solenoid Valve Armature Assembly for you to choose:



*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

photobank (10)photobank (11)photobank (12)photobank (8)



*According to tube material: Brass, Stainless Steel

photobank (8)photobank (12)photobank (18)photobank (11)



*According to valve application:

1. Pulse Solenoid Valve Armature Assembly, 2. Water Solenoid Valve Armature Assembly, 3. Pneumatic Solenoid Valve Armature Assembly, 4. Refrigeration Solenoid Valve Armature Assembly, 5. Injector Rail Armature Assembly, 6. Air-Jet Loom Solenoid Valve Armature Assembly, 7. House Appliances Solenoid Valve Armature Assembly, 8. Automobile Solenoid Valve Armature Assembly, 9. Medical Solenoid Valve Armature Assembly, etc.

photobank (14)photobank (16)photobank (17)photobank (10)
