| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | BDV |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/8'', 1/4'' | Body Orifice Size: | 1.5mm, 2.5mm, 3.0mm |
|---|---|---|---|
| Top Orifice Size: | 1.5mm | Operation Mode: | 3 Way Normally Closed, 3 Way Normally Open, Universal |
| Operation: | Direct Acting | Body Material: | Stainless Steel |
| Working Medium: | Water, Air, Oil, Etc | Seal Material: | NBR, FKM, EPDM |
| Pressure Range: | 0 To 1.6 MPa | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| High Light: | 3 Way Stainless Steel Solenoid Valve,3 Way Solenoid Valve Normally Closed,3 Way Solenoid Valve 24VDC |
||
1/8'' 1/4'' 3 Way Stainless Steel Solenoid Valve Normally Closed 24VDC 220VAC
Product Features of 3 Way Stainless Steel Solenoid Valve:
1. Working Medium: Water, Air, Oil, etc
2. Working Pressure Range: 0 to 1.6 MPa
3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃)
4. Port Size: 1/8'', 1/4''
5. Top Orifice Size: 1.5mm
6. Body Orifice Size: 1.5mm, 2.5mm, 3.0mm
7. Body Material: Brass, Stainless Steel
8. Diaphragm Material: NBR, EPDM, FKM
9. Function: 3 Way Normally Closed, 3 Way Normally Open, Universal
10. Operation: Direct Acting
11. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data of 3 Way Stainless Steel Solenoid Valve:
Main Dimension of 3 Way Stainless Steel Solenoid Valve:
Flow Diagrams of 3 Way Stainless Steel Solenoid Valve:
|
Universal Inlet: Any |
|
|
Normally Closed Inlet: 2 |
|
|
Normally Open Inlet: 3 |
|
Brando Factory Production Video of Solenoid Valves:
BRANDO Factory Production Picture of Solenoid Valves:
Packaging and Shiping of Brando Solenoid Valves:
|
|
|
| Internal Box | Carton | Pallet |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
