11mm OD 2/2 Way NC Flow Control Valve Armature Plunger Assembly

11mm OD 2/2 Way NC Flow Control Valve Armature Plunger Assembly

The shown is one kind of solenoid stem for pulse jet valve. Brando supply many brand pulse valve repair kit replacement armature, like BFEC (SBFEC), Goyen, ASCO, Turbo, Mecair, Norgren Buschjost, JOIL, AUTEL, Taeha and other Chinese brand. And we also supply related solenoid coils, diaphragms and pulse jet valves.

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

Detailed Images of solenoid valve stem:

Dimension & Data of solenoid valve stem:

Dimension	Model	BAPC211024535
	Function	2 Way, Normally Closed
	Seat Connection	Thread
	Core Tube Material	Stainless Steel
	Seal Material	NBR
	Voltage	All range of AC and DC available
	Application Example	Pulse Jet Valve
	Customize Service	Provided, Pls show us sample or drawing

Brando Solenoid Valve Stem Production Video:

Solenoid Valve Stem Categories:

*According to tube OD: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 30mm.

*According to tube material: Brass, Stainless Steel

*According to valve application: Our armatures are widely used in pneumatic, hydraulic, fluid control fields, covering textiles, home appliances, automobiles, refrigeration, dust collector and other automation control industries.

Features of Armature Assembly:

The main characteristics of the armature of solenoid valve can be reflected in the following aspects.

1. The static iron core is made of high magnetic conductivity, low remanence, antirust and corrosion-resistant materials, durable and responsive

2. The tube is made of copper or stainless steel, adopt rolling technology, and make the connection more closer and firmer.

3. The spring material is the imported stainless steel spring special steel wire, with stable pressure and good recovery performance

4. Sealing materials can be selected according to your different requirements

5. 3/2, 2/2 way; NO/NC; AC/DC various specifications for selection
