Name: 1.5'' 2'' 3'' Flanged Stainless Steel Steam Solenoid Valve Normally Open
Brand: Ningbo Brando Hardware Co., Ltd
SKU: PS-JFK
Price: 26.00 USD
Availability: InStock

Home Products Stainless Steel Solenoid Valve

1.5'' 2'' 3'' Flanged Stainless Steel Steam Solenoid Valve Normally Open

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	PS-JFK

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', 3''	Orifice Size:	18mm, 25mm, 32mm, 40mm, 50mm, 80mm
Operation Mode:	2 Way, Normally Open	Operation:	Piston Pilot Operated
Body Material:	Stainless Steel	Seal Material:	PTFE
Working Medium:	Steam, Hot Water, High Temp Liquid	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0.4 To 8 Bar	Temperature Range:	0 To +180℃
Highlight:	Steam Solenoid Valve 1.5'' , Steam Solenoid Valve Normally Open , Stainless Steel Steam Solenoid Valve

1.5'' 2'' 3'' Flanged Stainless Steel Steam Solenoid Valve Normally Open

Product Features of Steam Solenoid Valve:

1. Working Medium: Steam, High Temperature Liquid, etc.
2. Working Meidum Temperature Range: 0 to +180℃
3. Working Pressure Range: 0.4 to 16 bar
4. Function, 2 Way Normally Closed, 2 Way Normally Open
5. Operation: Piston Pilot Operated
6. Body Material: Brass, Stainless Steel, Cast Iron
7. Seal Material: PTFE
8. Port Size: 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2'', 2 1/2'', 3''
9. Pipe Connection: Flanged
10. Supply Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data of Steam Solenoid Valve:

Model	Orifice Size (mm)	Working Pressure (Bar)			Working Temperature (℃)	Coil Voltage
		Min	Max
			NC	NO
Stainless Steel Body
PS-15JF	18	0.4	16	8	0 to 180	220VAC 110VAC 24VAC 24VDC 12VDC
PS-20JF	18
PS-25JF	25
PS-32JF	32		12
PS-40JF	40
PS-50JF	50
PS-80JF	80		10	6
Brass Body
PS-25F	25	0.4	16	8	0 to 180	220VAC 110VAC 24VAC 24VDC 12VDC
PS-32F	32		12
PS-40F	40
PS-50F	50
Cast Iron Body
PS-65CF	53	0.4	10	6	0 to 180	220VAC 110VAC 24VAC 24VDC 12VDC

Main Dimension of Steam Solenoid Valve:

1.5'' 2'' 3'' Flanged Stainless Steel Steam Solenoid Valve Normally Open 0

Model	Dimension (mm)
Model	DN	L	D	H	K	d	C	f	n-φ
PS-15JF	18	106	95	165	65	46	14	2	4-φ14
PS-20JF	18	106	105	167	75	56	16	2	4-φ14
PS-25JF	25	135	115	190	85	65	16	3	4-φ14
PS-32JF	32	140	140	218	100	76	18	3	4-φ18
PS-40JF	40	148	150	228	110	84	18	3	4-φ18
PS-50JF	50	182	165	243	125	99	20	3	4-φ18
PS-80JF	80	278	200	324	160	132	20	3	4-φ18
PS-25F	25	118	115	187	85	65	16	3	4-φ14
PS-32F	32	140	140	218	100	76	18	3	4-φ18
PS-40F	40	150	150	230	110	84	18	3	4-φ18
PS-50F	50	185	165	245	125	99	20	3	4-φ18
PS-65CF	65	256	185	269	145	118	20	3	4-φ18

Brando Factory Production of Solenoid Valves:

More Steam Solenoid Valves for you to choose:

Brass Solenoid Valves

Stainless Steel Solenoid Valves

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
