| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 46B-F |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Inner boxes, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Medium: | Water, Air | Port Size: | 2-1/2'', 3'', 4'', 5'', 6'' |
|---|---|---|---|
| Pipe Connection: | Flanged | Function: | 2 Way Normally Closed |
| Operation: | Pilot Piston Operated | Diaphragm Material: | NBR, FKM, EPDM |
| Body Material: | Stainless Steel, Cast Steel | Working Pressure Range: | 0.1 To 2.5 MPa |
| Coil Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Coil Protection Class: | IP68, Waterproof |
| High Light: | Fountain Solenoid Valve 4'',Fountain Solenoid Valve 24V,Fountain Solenoid Valve IP68 Underwater |
||
4'' DN100 Flanged Water Fountain Solenoid Valve IP68 Underwater 24V 220V
BRANDO manufactures waterproof solenoid valve with IP68 protection class for underwater use. It can be used for 10 meters underwater. Available in Stainless Steel, Brass, Cast Steel and PVC material for your choice. Widely used in water fountain, SPA, swimming pool and any applications which require a waterproof solution.
1. Structure: Diaphragm Operated, Piston Operated
2. Function: Normally Closed or Normally Open
3. Body Material: Brass, Stainless Steel, Cast Steel, and PVC
4. Size Range: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2'', 3'', 4'', 5'', 6''
5. Connection Type: Threaded, Flanged
6. Seal Material: NBR, FKM, EPDM
7. Voltage.12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
8. Voltage Tolerance: +10%
9. Any special requirements, please consult us and we will help you resolve the issue and select the right valve!
Dimension of Fountain Solenoid Valve:
|
No
|
46B65F
|
46B80F
|
46B100F
|
46B125F
|
46B150F
|
|
L
|
290
|
310
|
350
|
400
|
480
|
|
D
|
185
|
200
|
220
|
250
|
285
|
|
D1
|
145
|
160
|
180
|
210
|
240
|
|
D2
|
118
|
132
|
156
|
184
|
211
|
|
B
|
20
|
20
|
22
|
22
|
24
|
|
F
|
3
|
||||
|
N-φD
|
4-φ18
|
8-φ18
|
8-φ22
|
||
Technical Data of Fountain Solenoid Valve:
Brando Factory Production of Solenoid Valves:
More Fountain Solenoid Valves for you to choose:
|
|
|
|
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
