Name: 2S350-35 1 1/4 Inch Stainless Steel Electric Solenoid Valve 24 Volt DC
Brand: Brando
SKU: 2S350-35
Rating: 4.9 (135 reviews)

Home Products Stainless Steel Solenoid Valve

2S350-35 1 1/4 Inch Stainless Steel Electric Solenoid Valve 24 Volt DC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2S350-35

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	1 1/4''	Orifice Size:	35mm
Operation Mode:	2 Way, Normally Closed	Action:	Direct Lifting Diaphragm
Body Material:	Stainless Steel 304	Seal Material:	NBR, FKM, EPDM
Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC	Pressure Range:	0 To 1 MPa
High Light:	1 1/4 Inch Stainless Steel Solenoid Valve , Stainless Steel Electric Solenoid Valve , Stainless Steel Solenoid Valve 24 Volt

2S350-35 1 1/4 Inch Stainless Steel Electric Solenoid Valve 24 Volt DC

Product Features:
1. Working Medium: Water, Air, Oil, Gas, etc.
2. Working Meidum Temperature Range: NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃
3. Working Pressure Range: 0 to 1 MPa
4. Function, 2 Way Normally Closed, 2 Way Normally Open
5. Operation: Direct Lifting Diaphragm
6. Body Material: Brass, Stainless Steel
7. Seal Material: NBR, FKM, EPDM
8. Port Size: 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
9. Thread Type: G, NPT
10. Supply Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Main Dimension of Solenoid Valve:

2S350-35 1 1/4 Inch Stainless Steel Electric Solenoid Valve 24 Volt DC 0

Model	Port Size	A	B	C
2S025-06	1/8''	35	35	76
2S025-08	1/4''	35	35	76
2S040-10	3/8''	44	44	88
2S160-10	3/8''	66	56	103
2S160-10-NO				125
2S160-15	1/2''	66	56	103
2S160-15-NO				125
2S200-20	3/4''	73	56	110
2S200-20-NO				132
2S250-25	1''	98	73	117
2S250-25-NO				139
2S350-35	1 1/4''	118	93	160
2S350-35-NO				180
2S400-40	1 1/2''	118	93	160
2S400-40-NO				180
2S500-50	2''	156	124	188
2S500-50-NO				209

Technical Data of Solenoid Valve:

Medium	Air, Water, Oil, Gas
Action	Direct Acting, Direct Lifting Diaphragm
Function	2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity	20 cst Below
Pressure	Normally Closed (0 to 1MPa), Normally Open (0 to 0.8MPa)
Temperature	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material	Stainless Steel 304
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type	Waterproof Coil, Round Coil, Square Coil, etc.
