SUW-25 2S250-25 1 Inch DN25 Stainless Steel Solenoid Valve

SUW-25 2S250-25 1 Inch DN25 Stainless Steel Solenoid Valve

2S250-25
2S: 2 Positon 2 Way Solenoid Valve. Solenoid valve has 2 pipe connections, an inlet called the cavity port and an outlet called the body orifice port. When the valve is energized the plunger opens allowing media to flow through the valve in the cavity port and out the body orifice port.Turn off the power. The orifice closes and flow through the valve stops.
250: The Aperture of Flow Rate is 25 mm
25:Joint Pipe Bore is G1 Inch Female Thread

A SUW-25/2S250-25 normally closed solenoid valve with a 304 Stainless Steel forged body and stainless steel operator. Suitable for low head and zero head applications with a coupled diaphragm and standard with NBR seat and seals. Stainless steel 2 way solenoid valves are suitable most general purpose air, water, vacuum, light oil applications however their stainless steel construction makes them an ideal flow solution for slightly aggressive media such as Reverse Osmosis Water, De-mineralised water, slight acid and alight alkali's making them an ideal choice for most food industry, pharmaceutical industry and chemical industry applications.

Dimension of 2W/2S Water Solenoid Valve :

Technical Data:

Product Features:
1. UW series is direct, multiplex, connected diaphragm, conductive and normally closed (NC) 2/2 way solenoid valve;

2. Able to be operated directly under low pressure;

3. Availability of fluid type:water, air, light oil;

4. Diaphragm accept for customization NBR, Viton, Silicone and EPDM.
