BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem

BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem

  • BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem
  • BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem
BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC213553538-L
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000pcs per month
Contact Now
Detailed Product Description
Position And Way: 2/2Way Voltage: AC, DC All Available
Mounting Type: Flange Guide Tube Outer Diameter: 13.5mm
Installation Height For Coil Assembling: 50.8mm Plunger Seal For Orifice Diameter: 10.5mm
Application: DMF Series Pulse Valve Guide Tube Material: Stainless Steel
High Light:

Dust Collector Solenoid Valve Stem

,

BFEC Solenoid Valve Stem

,

SBFEC Type Plunger Assembly

BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem



Fit for All SBFEC Type Pulse Jet Valve:
1. Right Angle Pulse Jet Valve: DMF-Z-20, DMF-Z-25, DMF-Z-40S, DMF-Z-50S, DMF-Z-62S, DMF-Z-76S, DMF-Z-102S
2. Quick Mount Pulse Jet Valve: DMF-ZL-B, DMF-ZM-20, DMF-ZM-25, DMF-ZM-40S
3. Immersion Pulse Jet Valve: DMF-Y-25, DMF-Y-40S, DMF-Y-50S, DMF-Y-62S, DMF-Y-76S, DMF-Y-102S
4. Straight Through Pulse Jet Valve: DMF-T-20, DMF-T-25S, DMF-T-40S, DMF-T-50S, DMF-T-62S
5. Flanged Pulse Jet Valve: DMF-ZF-25, DMF-ZF-40S



material of armature pure normally can’t be iron, but fe3o4. Most types of material for armature is iron alloy like manganese zinc ferrites, it is a new material that has about18000 magnetic conductivity.



Main dimension of Old Version SBFEC Type Pulse Valve Repair Kit:

Main dimension of Old Version SBFEC Type Pulse Valve Repair Kit



Technical Data About SBFEC Type Pulse Valve stem:

Model BAPC213553538
Type 2/2 Way
Function Normally Closed (NC)
Core Tube Material 304 Stainless steel
Moving Core Material Stainless steel 430FR
Seal Material VITON (FKM)
Suitable Coil Hole Diameter 13.5mm
Suitable Coil Height 50.8mm
Inlet Orifice Max 10.5mm
Voltage DC, AC
Connection Flange



Details:

BFEC Dust Collector Diaphragm Valve Solenoid Valve Stem 1



The Working Principle Of Pulse Valve:



The diaphragm divides the pulse solenoid valve into two chambers. When the compressed air is switched on, the compressed air enters the back chamber through the throttle hole. At this time, the pressure of the back chamber will press the diaphragm to close the output port of the valve, and the pulse solenoid valve is in a "closed" state. The electric signal of the pulse injection controller makes the armature of the pulse solenoid valve move, the vent of the back chamber of the valve opens, the back chamber loses pressure rapidly, the diaphragm moves backward, the compressed air is injected through the outlet of the valve, and the pulse solenoid valve is in the "open" state. when the electric signal of pulse jet control device vanishes and the armature of pulse solenoid valve is reset. The outlet of the back chamber is closed, and the pressure of the back chamber rises to make the diaphragm close to the valve outlet, and the pulse solenoid valve is in the "closed" state.



Product Features:
1. Fixed core and movable core (plunger):
Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.

2. Guide tube (plunger tube):
Options of brass and stainless steel, grade of H62 or SUS304;
Wall thickness from range of 0.25~2.5mm, others could be customized;
Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering. Machining from entire solid bar directly is also available.

3. Spring:
Rustproof SUS304 stainless steel, with good performance of restore.

4. Seals:
Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.

5 Shading ring:
Cooper and silver material available.

6. Washer and retaining nut can be provided if has demands.



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
