CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem

CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem

  • CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem
  • CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem
CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BAPC210030051
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 250000 sets per month
Contact Now
Detailed Product Description
Product Name: KIT CP1/4 Pilot Function: 2/2 Way, NC (Normally Closed)
Seat Connection Type: M14 X 1 Thread Armature Tube Material: Stainless Steel
Plunger Material: Stainless Steel 430FR Seal Material: NBR (Common), VITON (Option)
Suitable Coil Hole Diameter: φ10.0mm Suitable Coil Height: 28.7mm
Suitable Orifice Max: 5.6mm Applicable Valve Model: VNP 200/300/400/500/600/700 Series Pulse Valves
High Light:

CP1/4 Solenoid Valve Stem

,

Pulse Jet Solenoid Valve Stem

,

Autel Type CP1/4

CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem



The celow is KIT CP1/4 pilot (plunger tube and core) for repair and replace Mecair VNP 200, 300, 400, 500, 600, 700 series pulse valves. The related diaphragms repair kits are all supplied.



This is KIT CP1/4 pilot group is mounted on Mecair VNP 200, 300, 400, 500, 600, 700 doiaphragm pulse valves. Its 2/2 way normally closed function design conforms to the working principle of the pulse valve. And one set of CP1/4 consists of 1 stainless steel 304 core tube, 1 stainless steel 430FR plunger that adopts rustproof and corrosion-resistant material with high magnetic conductivity and low remanence, and 1 stainless steel 304 spring. The core tube and plunger can be sold separately.



The 200 series is a range of diaphragm valve suitable for Dust collector applications,in particular for reverse pulse jet fifer cleaning offilter bags, carridges, envelope filters, ceramic fiters and sintered metal fibre fiters.
The 200 sSeries valve has the inlet port at 90 to theoutlet port.The 200 Series range comprises 7 models, from 3/4" to 3 all with threaded female gas connections. The 1 1/2" model isavailable in the single and double diaphragm versions,while the 2',2 1/2" and 3" are all double diaphragm valves. The special designassures an extremely fast opening time, high flow rates and easy installation. The valves are constructed in die-cast aluminium and havean anodised protection treatment which protect them from corrosive and environmental agents.Bolts and screws are in stainless stel.
The 200 series is available in the following versions:
-VPN, with integrated solenoid pilot
-VEM,with remote pneumatic connection.





YouTube video of KIT CP1/4 Pilot Group With Core Tube And Plunger:



Main dimension of KIT CP1/4 Mecair Type Pulse Valve Repair Kit:

CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem 0



Details display of KIT CP1/4 Mecair Type Diaphragm Valve Repair Kit:

CP1/4 VNP VEM Series Dust Collector Pulse Jet Solenoid Valve Stem 1



Technical parameters of GPC 10 Pole Assembly Plunger Tube And Core:

Model Number
BAPC210030051
Guide Tube Outer Diameter
10.0mm
Installation Height for Coil Assembling
28.7mm
Plunger Seal for Orifice Diameter
5.6mm
Guide Tube Material
Stainless Steel
Seal Material
NBR, HNBR, FKM, EPDM, Silicone, all available
Connection Type
Thread
Voltage
All range of AC and DC available
Position and Way
2/2 Way
Non-working Status
Normally Closed
Application Examples
VNP 200/300/400/500/600/700 Series Pulse Valves
Customized Service
Provided, welcome show us sample or drawing



Tips: The related diaphragms are all supplied.



Factory production of Solenoid Valve Armature Plunger:



Product Features:
1. Fixed core and movable core (plunger): Adopting rustproof and corrosion-resistant material with high magnetic conductivity and low remanence to ensure armature assembly durable and smart acting.



2. Guide tube (plunger tube):
* Options of brass and stainless steel, grade of H62 or SUS304;
* Wall thickness from range of 0.25~2.5mm, others could be customized;
* Kinds of welding type to hold various working pressure, such as laser welding, argon-arc welding, silver soldering.

* Machining from entire solid bar directly is also available.



3. Spring: Rustproof SUS304 stainless steel, with good performance of restore.



4. Seals: Options of NBR, HNBR, FKM, EPDM, PTFE, food grade materials, welcome your other requirements.



5 Shading ring: Cooper and silver material available.



6. Washer and retaining nut provided if has demands.
