Name: Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2''
Brand: Brando
SKU: SUS-F
Rating: 4.6 (125 reviews)

Home Products Stainless Steel Solenoid Valve

Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2''

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	SUS-F

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	300000 sets per month

Contact Now

Detailed Product Description

Port Size:	1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''	Pipe Connection:	Flanged
Orifice Size:	15mm, 20mm, 25mm, 32mm, 40mm, 50mm	Function:	2 Way, Normally Closed
Operation:	Piston Pilot Operated	Body Material:	Stainless Steel
Seal Material:	PTFE ()	Working Pressure Range:	0.05 To 6 MPa
Voltages:	24VDC, 110VAC, 220VAC	Coil Protection Class:	IP65, IP67, Ex-proof
High Light:	Flange Mounted Solenoid Valve , Flange Type Solenoid Valve , Flange Connect Solenoid Valve

Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2''

1. Piston pilot operated solenoid valve, change quickly, start smooth, large flow.
2. Compact structure, small size, light weight, easy repair.
3. Body material stainless steel SUS304, solenoid valve coil heat-resistant grade H, rubber seal has better sealing performance and low pressure working conditions, wide range of applications.
4. PTFE () seals is suitable for a variety of working media, chemical fluids, especially for high temperature and steam, sealing performance is worse than rubber.
5. Coil protection class IP65, IP67 and explosion-proof, the connection mode has flying wire type, DIN socket type, for different occasions.
6. Long service life.

Main Dimension of SUS-F series Stainless Steel Solenoid Valve:

Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2'' 0

Model	L	H	A	B	C	D	K
SUS-15-F	115	155	47.5	95	65	14	15
SUS-15-F-NO		162
SUS-20-F	126	167	52.5	105	75	14	20
SUS-20-F-NO		174
SUS-25-F	143	178	57.5	115	85	14	25
SUS-25-F-NO		185
SUS-32-F	158	195	70	140	100	18	32
SUS-32-F-NO		202
SUS-40-F	181	211	75	150	110	18	40
SUS-40-F-NO		218
SUS-50-F	200	227	82.5	165	125	18	80
SUS-50-F-NO		234

Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2'' 1

Flanged Stainless Steel Solenoid Valve 1/2'' 3/4'' 1'' 1 1/4'' 1 1/2'' 2'' 2

Technical Data of SUS Series Stainless Steel Solenoid Valve:

Model	SUS-15	SUS-20	SUS-25	SUS-32	SUS-40	SUS-50
Model	SUS-15-NO	SUS-20-NO	SUS-25-NO	SIUS-32-NO	SUS-40-NO	SUS-50-NO
Port Size	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	15mm	20mm	25mm	32mm	40mm	50mm
Cv Value	5	6	13	20	28	39.5
Function	2 way, normally closed / normally open
Operation	Piston pilot operated
Body Material	Stainless steel 304
Seal Material	PTFE, FKM, EPDM
Working Temperature	PTFE: -20 to +180℃, FKM: -10 to +150℃, EPDM: -5 to +120℃
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Protection Class	IP65, IP67, Ex-proof
Insulation Class	F, H
Installation	Horizontal or Slant
