Name: 1.5'' 2 Way NO Piston Operated Solenoid Valve Stainless Steel 24V 220V
Brand: Brando
SKU: SUS-40-NO
Rating: 4.8 (157 reviews)

Home Products Stainless Steel Solenoid Valve

1.5'' 2 Way NO Piston Operated Solenoid Valve Stainless Steel 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	SUS-40-NO

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	negotiation
Packaging Details:	Inner Box, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability:	300000 sets per month

Contact Now

Detailed Product Description

Port Size:	1.5''	Orifice Size:	40mm
Function:	2 Way, NO	Operation:	Piston Pilot Operated
Body Material:	Stainless Steel	Seal Material:	PTFE ()
Voltages:	24VDC, 110VAC, 220VAC	Working Pressure Range:	0.05 To 6 MPa
High Light:	Piston Operated Solenoid Valve , Stainless Steel Solenoid Valve 1.5'' , 2 Way NO Solenoid Valve

1.5'' 2 Way NO Piston Operated Solenoid Valve Stainless Steel 24V 220V

1. Piston pilot operated solenoid valve, change quickly, start smooth, large flow.
2. Compact structure, small size, light weight, easy repair.
3. Body material stainless steel SUS304, solenoid valve coil heat-resistant grade H, rubber seal has better sealing performance and low pressure working conditions, wide range of applications.
4. PTFE () seals is suitable for a variety of working media, chemical fluids, especially for high temperature and steam, sealing performance is worse than rubber.
5. Coil protection class IP65, IP67 and explosion-proof, the connection mode has flying wire type, DIN socket type, for different occasions.
6. Long service life.

Main Dimension of SUS series Stainless Steel Solenoid Valve:

1.5'' 2 Way NO Piston Operated Solenoid Valve Stainless Steel 24V 220V 0

Model	L	H	A	B	φC	D	K
SUS-15	69	121	14	48.5	48	83.5	1/2''
SUS-15-NO		128
SUS-20	79	133	18	55.5			3/4''
SUS-20-NO		140
SUS-25	96	142	21	70			1''
SUS-25-NO		149
SUS-32	109	152	27	70			1 1/4''
SUS-32-NO		159
SUS-40	128	167	31	95			1 1/2''
SUS-40-NO		174
SUS-50	150	183	38	100			2''
SUS-50-NO		190

Technical Data of SUS Series Stainless Steel Solenoid Valve:

Model	SUS-15	SUS-20	SUS-25	SUS-32	SUS-40	SUS-50
Model	SUS-15-NO	SUS-20-NO	SUS-25-NO	SIUS-32-NO	SUS-40-NO	SUS-50-NO
Port Size	1/2''	3/4''	1''	1 1/4''	1 1/2''	2''
Orifice Size	15mm	20mm	25mm	32mm	40mm	50mm
Cv Value	5	6	13	20	28	39.5
Function	2 way, normally closed / normally open
Operation	Piston pilot operated
Body Material	Stainless steel 304
Seal Material	PTFE, FKM, EPDM
Working Temperature	PTFE: -20 to +180℃, FKM: -10 to +150℃, EPDM: -5 to +120℃
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Protection Class	IP65, IP67, Ex-proof
Insulation Class	F, H
Installation	Horizontal or Slant
