PTFE Seal 2 Way NC Stainless Steel Solenoid Valve 3/8'' 24V 220V

PTFE Seal 2 Way NC Stainless Steel Solenoid Valve 3/8'' 24V 220V

  • PTFE Seal 2 Way NC Stainless Steel Solenoid Valve 3/8'' 24V 220V
PTFE Seal 2 Way NC Stainless Steel Solenoid Valve 3/8'' 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: SUS-10
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Port Size: 3/8'' Orifice Size: 2.0mm, 2.5mm, 3mm, 4mm, 5mm
Function: 2 Way, Normally Closed Operation: Direct Acting
Body Material: Stainless Steel Seal Material: PTFE
Voltages: 24VDC, 110VAC, 220VAC Working Pressure Range: 0 To 7 MPa
High Light:

Stainless Steel Solenoid Valve 3/8''

,

2 Way NC Solenoid Valve

,

Solenoid Valve PTFE Seal

1/4'' 2 Way NO PTFE Seal Stainless Steel Solenoid Valve 24V 220V



Stainless Steel Solenoid Valves are manufactured and designed to suit a range of applications and media including: clear liquids and gases such as water, compressed air and slightly more aggressive chemicals. Available to order online in normally closed or normally open function, direct acting, assisted lift or servo assisted with various seal materials, ratings and sizes from 1/8'' up to 3''.



Main Dimension of SUS series Stainless Steel Solenoid Valve:

PTFE Seal 2 Way NC Stainless Steel Solenoid Valve 3/8'' 24V 220V 0

Model
A
B
φC
D
F
G
K
H
SUS-08
10.5
35
48
83.5
M5
20
1/4''
89
SUS-08-NO
96
SUS-10
11.5
44
M5
27
3/8''
93
SUS-10-NO
100



Technical Data of SUS Series Stainless Steel Solenoid Valve:

Port Size
1/4'', 3/8''
Orifice Size
2.0mm
2.5mm
3mm
4mm
5mm
Cv Value
0.13
0.18
0.25
0.53
0.85
Function
2 Way, Normally Closed / Normally Open
Operation
Direct Acting
Body Material
Stainless Steel 304
Medium
Steam, Air, Water, Light Oil (below 50cst fluid),
micro-corrosive media, multiple chemical fluids
Seal Material
FKM, PTFE, EPDM
Working Temperature
FKM: -10 to +150℃, PTFE: -20 to +180℃, , EPDM: -5 to 120℃
Voltages
12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Protection Class
IP65, IP67, Ex-Proof
Insulation Class
H, F
Installation
Horizontal or Slant
