Name: 2S500-50 2'' 2 Way NC Water Solenoid Valve Stainless Steel 24VDC 220VAC
Brand: Brando
SKU: 2S500-50
Rating: 4.8 (120 reviews)

Home Products Stainless Steel Solenoid Valve

2S500-50 2'' 2 Way NC Water Solenoid Valve Stainless Steel 24VDC 220VAC

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	2S500-50

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Inner boxes, Carton, Pallet
Delivery Time:	4-8 days
Payment Terms:	L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Port Size:	2''	Orifice Size:	50mm
Operation Mode:	2 Way, Normally Closed	Action:	Direct Lifting Diaphragm
Working Fluids:	Air, Water, Oil, Gas	Body Material:	Stainless Steel 304
Seal Material:	NBR	Voltages:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Pressure Range:	0 To 1 MPa	Temperature Range:	-5 To +80 ℃
High Light:	2 Inch Water Solenoid Valve , Solenoid Valve Stainless Steel , 24VDC Water Solenoid Valve

2S500-50 2'' 2 Way NC Water Solenoid Valve Stainless Steel 24VDC 220VAC

Normally closed solenoid valves are closed unless energized. Once energized, they immediately open, and stay open for as long as energy is applied. Because of how they open, these valves are not intended for long term, continuous energization. They are a great choice for tasks where immediate opening and closing, for relatively short periods of time, is a necessity.

Main Dimension of Solenoid Valve:

2S500-50 2'' 2 Way NC Water Solenoid Valve Stainless Steel 24VDC 220VAC 0

Model	Port Size	A	B	C
2S025-06	1/8''	35	35	76
2S025-08	1/4''	35	35	76
2S040-10	3/8''	44	44	88
2S160-10	3/8''	66	56	103
2S160-10-NO				125
2S160-15	1/2''	66	56	103
2S160-15-NO				125
2S200-20	3/4''	73	56	110
2S200-20-NO				132
2S250-25	1''	98	73	117
2S250-25-NO				139
2S350-35	1 1/4''	118	93	160
2S350-35-NO				180
2S400-40	1 1/2''	118	93	160
2S400-40-NO				180
2S500-50	2''	156	124	188
2S500-50-NO				209

Technical Data of Solenoid Valve:

Medium	Air, Water, Oil, Gas
Action	Direct Acting, Direct Lifting Diaphragm
Function	2 Way, Normally Closed (NC), Normally Open (NO)
Viscocity	20 cst Below
Pressure	Normally Closed (0 to 1MPa), Normally Open (0 to 0.8MPa)
Temperature	NBR: -5 to +80℃, EPDM: -5 to +120℃, FKM: -5 to +150℃, Silicone: -15 to +150℃
Body Material	Stainless Steel 304
Voltages	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Type	Waterproof Coil, Round Coil, Square Coil, etc.
