2S160-15 SUW-15 1/2'' Inch Normally Closed Stainless Steel Solenoid Valve

2S160-15 SUW-15 1/2'' Inch Normally Closed Stainless Steel Solenoid Valve

The valve is a two position two way solenoid valve, the structure of which is mainly composed of a pilot valve and a main valve, and the main valve adopts a rubber sealing structure.

The 2s series normally closed solenoid valve is made of stainless steel and is more durable. Suitable for air, compressed air, water, oil and other media, low noise, high reliability, can work normally in extreme environments.

2S160-15

2S: 2 Position 2 Way Direct Drive Solenoid Valve With Stainless Steel Body

160: The Orifice Size of 2S160-15 Solenoid Valve is 16 mm

15: The Port Size of 2S160-15 Solenoid Valve is G 1/2''

Technical Data of 2W & 2S Solenoid Valve:

Main dimension of 2W & 2S Series Solenoid Valves:

The difference between Normally Close and Normally Open Solenoid Valve

Normally open solenoid valve
Normally open solenoid valve is closed when the solenoid coil is powered, and the normally closed solenoid valve is open when the solenoid coil is off. If the solenoid valve is required long-term opening, the normally open solenoid valve will be the ideal choice. If the solenoid valve is required long-term opening or close, the bistable solenoid valve is more suitable. As for the voltage, AC (380V, 240V, 220V, 24V) and DC (110V, 24V) is applicable for the normally open solenoid valve.

Normally open solenoid valve applies to the actuator that using steam as heat medium and automatically control temperature. normally open solenoid valve can make two-position automatic control and remote control to the steam heater, radiator, dryer and other steaming plants. Normally open solenoid valve has wide applications, including dyeing, textile, printing and dyeing, food, medicine, tobacco, cement product, petrochemical industry, metallurgy and etc.

Normally closed solenoid valve
Normally closed solenoid valve means closed when the solenoid coil is powered, and the solenoid valve is open when the solenoid coil is off. Normally closed solenoid valve apply for international standard voltage include AC 380V, 240v, 220v, 24v or DC 110V, 24V.
