| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | EVR6-012S |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Port Size: | 1/2'' | Function: | NC |
|---|---|---|---|
| Coil: | No | Valve Operation: | Servo-Operated |
| Inlet & Outlet Connection: | ODF Solder | Body Material: | Brass |
| Application: | Refrigeration Part | ||
| Highlight: | 032L1209 Air Conditioner Valve,032L7144 Air Conditioner Valve,Danfoss Type EVR 6 |
||
032L1209 032L7144 032L7308 EVR 6 1/2'' Inch Solder Air Conditioner Valve
032L1209 EVR6-012S Servo-Operated Solenoid Valves for Air Conditioning Systems Without Coil
s Type solenoid Valve refrigeration System Controls with ODF Solder connection. EVR valves can be used in liquid, suction and hot gas lines, and the valves are compatible with fluorinated refrigerants, including high-pressure refrigerants such as R410A. Can be used for various occasions like cold storage, freezing and air conditioning devices occasions. Extended ends on solder versions make the installation easy. It is not necessary to dismantle the valve when soldering in. Available in flare, solder and flange conection versions.
EVR Solenoid Valves
Suitable for all refrigeration, freezing, and air conditioning applications and are compatible with fluorinated refrigerants
Laser engraved product information for lasting information for lasting product identification of valve type
Hermetic, laser welded, non-replaceable stainless steel power head
Robust stainless steel capillary tube and sensing bulb
Bulb charges optimized for A/C or refrigeration
Adjustable superheat
Dimension:
Data Sheet Of EVR Series:
|
Type
|
Connection size (inch)
|
Connection size
(mm)
|
Max. working Pressure
(bar)
|
Kv value
(m3/h)
|
Code NO.
|
|
EVR 2
|
1/4
|
-
|
45.2
|
0.15
|
032F1201
|
|
-
|
6
|
45.2
|
0.15
|
032F1202
|
|
|
EVR 3
|
1/4
|
-
|
45.2
|
0.26
|
032F1206
|
|
3/8
|
-
|
45.2
|
0.26
|
032F1204
|
|
|
-
|
6
|
45.2
|
0.26
|
032F1207
|
|
|
-
|
10
|
45.2
|
0.26
|
032F1208
|
|
|
EVR 6
|
1/2
|
-
|
45.2
|
0.80
|
032L1209
|
|
3/8
|
-
|
45.2
|
0.80
|
032L1212
|
|
|
-
|
10
|
45.2
|
0.80
|
032L1213
|
|
|
-
|
12
|
45.2
|
0.80
|
032L1236
|
|
|
EVR 10
|
1/2
|
-
|
35
|
1.9
|
032L1217
|
|
-
|
12
|
35
|
1.9
|
032L1218
|
|
|
5/8
|
16
|
35
|
1.9
|
032L1214
|
|
|
EVR 15
|
7/8
|
22
|
32
|
2.6
|
032L1225
|
|
5/8
|
16
|
32
|
2.6
|
032L1228
|
|
|
EVR 20
|
7/8
|
22
|
32
|
5.0
|
032L1240
|
|
1 1/8
|
-
|
32
|
5.0
|
032L1244
|
|
|
-
|
28
|
32
|
5.0
|
032L1245
|
|
|
7/8
|
22
|
32
|
5.0
|
032L1264
|
|
|
EVR 22
|
1 3/8
|
35
|
32
|
6.0
|
032L3267
|
|
EVR 25
|
1 1/8
|
-
|
32
|
10.0
|
032L2201
|
|
-
|
28
|
32
|
10.0
|
032L2206
|
|
|
1 3/8
|
-
|
32
|
10.0
|
032L2207
|
|
|
1 3/8
|
-
|
32
|
10.0
|
032L2208
|
|
|
EVR 32
|
1 5/8
|
-
|
32
|
10.0
|
042L1104
|
|
-
|
35
|
32
|
16.0
|
042L1105
|
|
|
-
|
35
|
32
|
16.0
|
042L1106
|
|
|
-
|
42
|
32
|
32
|
042L1108
|
|
|
EVR 40
|
1 5/8
|
-
|
32
|
32
|
042L1110
|
|
2 1/8
|
-
|
32
|
32
|
042L1112
|
|
|
|
42
|
32
|
32
|
042L1114
|
Feature:
Complete range of solenoid valves for refrigeration, freezing and air conditioning plant
Supplied in versions normally closed (NC) and normally open (NO) with de-energized coil
Wide choice of coils for a.c. and d.c.
Suitable for all fluorinated refrigerants,including flammable refrigerants
Designed for media temperatures up to 105 °C
MOPD up to 25 bar with 12 W coil
Flare connections up to 5/8 in.
Solder connections up to 2 1/8 in.
Extended ends on solder versions make the installation easy. It is not necessary to dismantle the valve when soldering in.
Available in flare, solder and flange conection versions
