| Place of Origin: | CHINA |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | AC3000-03 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | negotiation |
| Packaging Details: | bubble bag, inner box, carton, then pallet |
| Delivery Time: | 7 working days after payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000pcs per month |
| Product Name: | Filter Regulator Lubricator | Model: | AC1000, AC2000, AC2500, AC3000, AC4000, AC5000, AC5500, AC6000 |
|---|---|---|---|
| Fluid: | Air | Port Size: | M5, 1/8'', 1/4'', 3/8'', 1/2'', 3/4'', 1'' |
| Filtering Grade: | 5 μm | Max Pressure: | 1.0Mpa (145Psi) |
| Proof Pressure: | 1.5Mpa (215Psi) | Recommended Lubricant: | ISO VG 32 Or Equivalent |
| High Light: | SMC Filter Regulator And Lubricator,SMC FRL 3/8'',SMC AC3000-03 |
||
AC3000-03 SMC Type FRL Unit Pneumatic Air Filter Regulator Lubricator
FRL - Filter Regulator Lubricator
Air leaving a compressor is hot, dirty, and wet – which can damage and shorten the life of downstream equipment, such as valves and cylinders. Before this air can be used, it needs to be cleaned and lubricated. That’s where an FRL comes in! An FRL combines a filter, regulator, and lubricator into one component to keep air compressor systems in optimal working condition.
FRL Components
An FRL is comprised of three primary components:
1. Airline filter
2. Pressure regulator
3. Lubricator
Specification of AC series Filter Regulator Lubricator:
| Model | AC1000 | AC200 | AC2500 | AC3000 | AC4000 | AC4000-06 | AC5000 | AC5500 | AC6000 | |
|
Combination Equipment |
Filter | AF1000 | AF2000 | AF2500 | AF3000 | AF4000 | AF4000-06 | AF5000 | AF6000 | AF6000 |
| Regulator | AR1000 | AR2000 | AR2500 | AR3000 | AR4000 | AR4000-06 | AR5000 | AR5000 | AR6000 | |
| Lubricator | AL1000 | AL2000 | AL2500 | AL3000 | AL4000 | AL4000-06 | AL5000 | AL6000 | AL6000 | |
| Port Size | M5 |
1/8'' 1/4'' |
1/4'' 3/8'' |
1/4'' 3/8'' |
1/4'' 3/8'' 1/2'' |
3/4'' |
3/4'' 1'' |
1'' | 1'' | |
| Gauge Port Size | 1/16'' | 1/8'' | 1/8'' | 1/8'' | 1/4'' | 1/4'' | 1/4'' | 1/4'' | 1/4'' | |
| Fluid | Air | |||||||||
| Proof Pressure | 1.5 MPa | |||||||||
| Max Operating Pressure | 1.0 MPa | |||||||||
| Set pressure range | 0.05 to 0.7 MPa | 0.05 to 0.85 MPa | ||||||||
| Flow (L/MinANR)) | 90 | 500 | 1500 | 2000 | 4000 | 4500 | 5000 | 6000 | 6000 | |
| Ambient And Fluid Temperature | -5 to 60 ℃ (Non-freezing) | |||||||||
| Filtration | 5μm | |||||||||
| Recommand Lubricant | Turbin oil class (ISO BG32) | |||||||||
| Bowl Material | Polycarbonate | |||||||||
| Construction/Regulator | Relieving style | |||||||||
Dimension of AC series Filter Regulator Lubricator:
Combinations of AC series Filter Regulator Lubricator:
Other Pneumatic Products BRANDO supply:
| 2/2 Way Pneumatic Valves | 3/2 Way Pneumatic Valves | 5/2 Way Pneumatic Valves | 5/3 Way Pneumatic Valves |
|
|
|
|
| Namur Solenoid Valves | Air Pilot Valves | Pneumatic Cylinders | Silencers and Fittings |
|
|
|
|
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
