1079/7 7/8'' Solder Diaphragm Pilot Operator Refrigeration Solenoid Valve

1079/7 7/8'' Solder Diaphragm Pilot Operator Refrigeration Solenoid Valve

1079/7S: 7/8'' Inch ODS Connection Diaphragm Pilot Operated NC Refrigeration Solenoid Valve ODS Connection Without Coil.

1079/7A6: 7/8'' Inch ODS Connection Diaphragm Pilot Operated NC Refrigeration Solenoid Valve ODS Connection With 220/230 VAC(A6) Coil.

1079/7A7: 7/8'' Inch ODS Connection Diaphragm Pilot Operated NC Refrigeration Solenoid Valve ODS Connection With 240 VAC(A7) Coil.

HF2 HF3 HM2 HM3 HM4 CM2 Coil can be mounted on the valve.

The shown is 1079/7 solenoid valve, 7/8'' ODS solder port size, 2 way normally closed, 220/230VAC (50/60Hz), 240VAC voltages (other voltages can be customized), ordering code: 1079/7, 1079/7S, 1079/7A6, 1079/7A7.

Applicability
The fluid in the pipeline must be consistent with the medium calibrated in the selected solenoid valve series model.
The temperature of the fluid must be lower than the calibration temperature of the solenoid valve.
The allowable liquid viscosity of the solenoid valve is generally below 20CST, and it should be noted if it is greater than 20CST.
Working pressure difference. When the maximum pipeline pressure difference is less than 0.04MPa, direct-acting and stepwise direct-acting types such as ZS, 2W, ZQDF, ZCM series should be selected; pilot type (pressure Differential) Solenoid valve; the maximum working pressure difference should be less than the maximum calibrated pressure of the solenoid valve; general solenoid valves work in one direction, so pay attention to whether there is a back pressure difference, and install a check valve if any.

1. Refrigeration Solenoid Valve:
* Danfoss Type: EVR 3, EVR 6, EVR 10, EVR 15, EVR 20, EVR 22, EVR 25, EVR 32, EVR 25, EVRA 25, EVRA 32, EVRA 40;
* Castel Type: 1020/2, 1020/3, 1064/3, 1064/4, 1070/4, 1070/5, 1070/6, 1090/5, 1090/6, 1028/2, 1028/3, 1068/3, 1068/4, 1078/4, 1078/5, 1079/7, 1078/9, 1079/11, 1079/7, 1099/11, 1078/11, 1079/13.

2. Refrigerator Solenoid Valve: FDF, SDF ......

3. Expansion Valve: Thermostatic / Thermal Expansion Valve, Automatic Expansion Valve, Electronic Expansion Valve ......

Dimension & Data of Castel Type Solenoid Valve:

Product video of 1079/7 Castel Type Solenoid Valve:

More Refrigeration Valve For you to choose:

   Danfoss Type Solenoid Valve       Ammonia Refrigeration Valve     Castel Type Solenoid Valve

Refrigeration Solenoid Valve Coil          Expansion Valve               Refrigerator Solenoid Valve
