Castel Type 1028/2 1/4'' ODS Air Conditioner HM2 Solenoid Valve

Castel Type 1028/2 1/4'' ODS Air Conditioner HM2 Solenoid Valve

The shown is castel type 1028/2 solenoid valve, 1/4'' ODS solder port size, 2 way normally closed, 220/230VAC (50/60Hz), 240VAC voltages (other voltages can be customized), ordering code: 1028/2, 1028/2S, 1028/2A6, 1028/2A7.

The primary purpose of a solenoid valve in a refrigerant liquid line is to prevent flow into the evaporator during the off cycle. On multiple systems, a solenoid valve may be used in each liquid line leading to the individual evaporators. The application of a liquid-line solenoid valve depends mainly on the method of wiring the valve with the compressor control circuit.

Direct Acting Solenoid Valve
Principle: When energized, the solenoid generates electromagnetic force to lift the closing member from the valve seat, and the valve opens; when the power is off, the electromagnetic force disappears, and the spring presses the closing member on the valve seat, and the valve closes.
Features: It can work normally under vacuum, negative pressure and zero pressure, but the diameter generally does not exceed 25mm.

Dimension & Data of Castel Type Solenoid Valve:

Product video of 1028/2 Castel Type Solenoid Valve:
