Name: 1020/2 1/4'' SAE Flare Normally Closed Refrigeration Solenoid Valve
Brand: Brando
SKU: 1020/2
Rating: 4.5 (147 reviews)

Home Products Refrigeration Solenoid Valve

1020/2 1/4'' SAE Flare Normally Closed Refrigeration Solenoid Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	1020/2

Payment & Shipping Terms:

Minimum Order Quantity:	100 PCS
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Screw Connections:	1/4 "SAE	Power:	Solenoid
Media:	Refrigerant	Structure:	Direct Acting
Material:	Brass	Function:	Normally Closed
Voltages:	AC110V, AC220V, DC24V	Ambient Temperature:	-35 - 105 °C
Application:	Refrigeration Parts	Refrigerants:	R125 R134a R152a R22 R404A R407A R407C
High Light:	1020/2 Refrigeration Solenoid Valve , 1/4'' SAE Refrigeration Solenoid Valve , Castel Type Refrigeration Valve

1020/2 1/4'' SAE Flare Normally Closed Refrigeration Solenoid Valve

1020/2S: 1/4'' Direct Acting NC Refrigeration Solenoid Valve SAE Flare Connection Without Coil.

1020/2A6: 1/4'' Direct Acting NC Refrigeration Solenoid Valve SAE Flare Connection With 220/230 VAC(A6) Coil.

1020/2A7: 1/4'' Direct Acting NC Refrigeration Solenoid Valve SAE Flare Connection With 240 VAC(A7) Coil.

HF2 HF3 HM2 HM3 HM4 CM2 Coil can be mounted on the valve.

Distributed direct-acting solenoid valve
Principle: It is a principle that combines direct action and pilot type. When there is no pressure difference between the inlet and the outlet, the electromagnetic force directly lifts the pilot small valve and the main valve closing member upwards in turn, and the valve opens. When the inlet and outlet reach the starting pressure difference, after power on, the electromagnetic force pilots the small valve, the pressure in the lower chamber of the main valve rises, and the pressure in the upper chamber drops, so that the pressure difference pushes the main valve upward; when the power is off, the pilot valve uses a spring The force or medium pressure pushes the closing piece and moves downward to close the valve.
Features: It can also be operated under zero pressure difference or vacuum and high pressure, but the power is large, and it must be installed horizontally.

Technical Data:

Operating Principles	Model Number	SAE Port	Seat size nominal Ø [mm]	Kv Factor [m3/h]	PS [bar]	TS[℃]		TA[℃]
						min	max	min	max
Direct Acting	1020/2	1/4''	2, 5	0, 175	45	-35	+110	-35	+50
	1020/3	3/8''	3	0, 23
Diaphragm Pilot Operated	1064/3	3/8''	6, 5	0, 80	45	-35	+105	-35	+50
	1064/4	1/2''
	1070/4	1/2''	12, 5	2, 20
	1070/5	5/8''		2, 61
	1090/5	5/8''	16, 5	3, 80
	1090/6	3/4''		4, 80
Piston Pilot Operated	1034/3	3/8''	6, 5	1, 00	45	-35	+110	-35	+50
	1034/4	1/2''
	1040/4	1/2''	12, 5	2, 40
	1040/5	5/8''		3, 00
	1050/5	5/8''	16, 5	3, 80
	1050/6	3/4''		4, 80

Dimension:

1020/2 1/4'' SAE Flare Normally Closed Refrigeration Solenoid Valve 0

Replacement Castel Type Solenoid Coil:

1020/2 1/4'' SAE Flare Normally Closed Refrigeration Solenoid Valve 1

APPLICATION
The solenoid valves illustrated in this chapter are designed for installation on commercial refrigeration systems and on civil and industrial air conditioning plants that use the following refrigerant fluids:
• HCFC (R22)
• HFC (R134a , R404A , R407C , R410A , R507)
• HFO and HFO/HFC mixtures (R1234ze , R448A , R449A, R450A , and R452A)

Furthermore, the same solenoid valves, up to DN 25, that is models 1078*9, 1098/9, 1079/11 and 1099/11, can also be installed on systems using the following refrigeration fluids:
• HFC (R32)
• HFO (R1234yf)
