| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | EVRA 25 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual Boxes, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Ammonia Refrigration Valve | Ordering Number: | EVRA 25, JS1025, 032F6225, 032F6226 |
|---|---|---|---|
| Orifice Size: | 25mm | Voltages: | 12V DC, 24V DC, 24V AC, 110V AC, 220V AC |
| Operation: | Servo Piston Operated | Connection Type: | Flange |
| System Line Application: | Discharge Line, Hot Gas Defrost Line, Liquid Line, Suction Line | Application: | Ammonia Chiller |
| High Light: | Danfoss Solenoid Valve Ammonia,Danfoss JS1025 Solenoid Valve,Danfoss HT JS1025 |
||
Ammonia Solenoid Valve Danfoss Type EVRA 25 HT JS1025 EN-JS1025
EVRA is a direct or servo operated solenoid valve for liquid, suction and hot gas lines with ammonia or fluorinated refrigerants. EVRA valves are supplied complete or as separate components, i.e. valve body, coil and flanges can be ordered separately.
EVRA 25, 32 and 40 are servo operated piston valves.The valves are closed with currentless coil.The servo piston with main valve plate closes against the valve seat by means of the differential pressure between inlet and outlet side of the valve, the force of the compression spring and possibly the piston weight. When current to the coil is switched on, the pilot orifice opens. This relieves the pressure on the piston spring side of the valve. The differential pressure will then open the valve. The minimum differential pressure needed for full opening of the valves is 0.2 bar.
Data of EVRA Series Ammonia Solenoid Valves:
Main dimension of EVRA Series Ammonia Solenoid Valve:
|
Model
|
H1
|
H2
|
H4
|
L
|
L1
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
|
|
EVRA 15
|
/
|
100
|
81
|
130
|
68
|
|
EVRA 25
|
46
|
141
|
78
|
162
|
92
|
|
EVRA 32
|
47
|
115
|
53
|
175
|
/
|
|
EVRA 40
|
47
|
115
|
53
|
175
|
/
|
Product video of EVRA Series Ammonia Solenoid Valves:
Packaging of EVRA 25 Ammonia Solenoid Valve:
