Discharge Line, Hot Gas Defrost Line, Liquid Line, Suction Line
Application:
Chiller, Freezer, Air Conditioning, Cooler, Etc
Highlight:
HVAC Liquid Line Solenoid Valve
,
Danfoss 5/8'' Solenoid Valve
,
Danfoss 032L1228
HVAC Liquid Line Solenoid Valve Danfoss Type EVR 15 NC 5/8'' 032L1228
The shown is danfoss type EVR 15 solenoid valve, 5/8'' (16mm) ODF solder port size, 2 way normally closed, 12V DC, 24V DC, 24V AC, 110V AC, 220V AC voltages (other voltages can be customized), ordering code: 032F1228, 032L1228.
BRANDO offers a wide variety of solenoid valve sizes and styles which may be employed in refrigeration and air conditioning systems to electrically control refrigerant flow. Solenoid valves are electrically operated ''stop-valves''. These are either fully open or fully closed. Remember these do not modulate flow.
Main Dimension of EVR Series Solenoid Valve:
Model
Port Size
H1
H2
L
L2
SAE (Flare)
ODF (Solder)
Inch
mm
mm
mm
mm
mm
EVR 3
EVR 3
1/4''
6
14
71
102
7
EVR 3
EVR 3
3/8''
10
14
73
117
10
EVR 6
EVR 6
3/8''
10
14
79
111
10
EVR 6
EVR 6
1/2''
12.8
14
79
127
10
EVR 10
EVR 10
1/2''
12.8
16
79
127
10
EVR 10
EVR 10
5/8''
16
16
79
160
12
EVR 15
5/8''
16
19
86
176
12
EVR15
7/8''
22
19
86
176
17
EVR 20
7/8''
22
20
90
191
17
EVR 20
1 1/8''
28.8
20
90
214
22
EVR 22
1 3/8''
35
20
90
281
25
EVR 25
1 1/8''
28.8
38
138
256
22
EVR25
1 3/8''
35
38
138
281
25
EVR 32
1 3/8''
35
47
111
281
25
EVR 32
1 5/8''
42
47
111
281
29
EVR 40
1 5/8''
42
47
111
281
29
EVR 40
2 1/8''
54
47
111
281
34
Product Video of EVR 15 5/8'' Danfoss Type Solenoid Valve:
Ordering Code of EVR Solder Connections, Normally Closed (NC) - Separate Valve Bodies:
Ordering Code of EVR Flare Connections, Normally Closed (NC) - Separate Valve Bodies:
