| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | EVR 10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual Boxes, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Refrigeration Solenoid Valve | Ordering Number: | 032F1217, 032L1217 |
|---|---|---|---|
| Port Size: | 1/2'' (12mm) | Connection Type: | Solder (ODF) |
| Function: | 2 Way, Normally Closed | Voltages: | 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC |
| Body Material: | Brass | Seal Material: | PTFE |
| System Line Application: | Discharge Line, Hot Gas Defrost Line, Liquid Line, Suction Line | Application: | Chiller, Freezer, Air Conditioning, Cooler, Etc |
| High Light: | 1/2'' Refrigeration Solenoid Valve,Danfoss EVR 10 Solenoid Valve,Danfoss 032F1217 |
||
1/2'' Refrigeration Solenoid Valve Danfoss Type EVR 10 032F1217
The shown is danfoss type EVR 10 solenoid valve, 1/2'' (12mm) ODF solder port size, 2 way normally closed, 12V DC, 24V DC, 24V AC, 110V AC, 220V AC voltages (other voltages can be customized), ordering code: 032F1217, 032L1217. Danfoss type EVR solenoid valve (NC) is a normally closed, direct or servo operated solenoid valve for liquid, suction and hot gas lines with fluorinated refrigerants. EVR valves are supplied complete or as separate components, i.e. valve body, coil and flanges.
Features and benefits:
1. Supplied in versions normally closed (NC) and normally open (NO) with de-energized coil
2. Wide choice of coils for a.c. and d.c.
3. Suitable for all fluorinated refrigerants
4. Designed for media temperatures up to 105 °C
5. Maximum Operating Pressure (MOP) up to 25 bar with 12 W coil
6. Easy installation with either flare, solder or flanged connections
Main Dimension of EVR Series Solenoid Valve:
|
Model
|
Port Size
|
H1
|
H2
|
L
|
L2
|
||
|
SAE (Flare)
|
ODF (Solder)
|
Inch
|
mm
|
mm
|
mm
|
mm
|
mm
|
|
EVR 3
|
EVR 3
|
1/4''
|
6
|
14
|
71
|
102
|
7
|
|
EVR 3
|
EVR 3
|
3/8''
|
10
|
14
|
73
|
117
|
10
|
|
EVR 6
|
EVR 6
|
3/8''
|
10
|
14
|
79
|
111
|
10
|
|
EVR 6
|
EVR 6
|
1/2''
|
12.8
|
14
|
79
|
127
|
10
|
|
EVR 10
|
EVR 10
|
1/2''
|
12.8
|
16
|
79
|
127
|
10
|
|
EVR 10
|
EVR 10
|
5/8''
|
16
|
16
|
79
|
160
|
12
|
|
|
EVR 15
|
5/8''
|
16
|
19
|
86
|
176
|
12
|
|
|
EVR15
|
7/8''
|
22
|
19
|
86
|
176
|
17
|
|
|
EVR 20
|
7/8''
|
22
|
20
|
90
|
191
|
17
|
|
|
EVR 20
|
1 1/8''
|
28.8
|
20
|
90
|
214
|
22
|
|
|
EVR 22
|
1 3/8''
|
35
|
20
|
90
|
281
|
25
|
|
|
EVR 25
|
1 1/8''
|
28.8
|
38
|
138
|
256
|
22
|
|
|
EVR25
|
1 3/8''
|
35
|
38
|
138
|
281
|
25
|
|
|
EVR 32
|
1 3/8''
|
35
|
47
|
111
|
281
|
25
|
|
|
EVR 32
|
1 5/8''
|
42
|
47
|
111
|
281
|
29
|
|
|
EVR 40
|
1 5/8''
|
42
|
47
|
111
|
281
|
29
|
|
|
EVR 40
|
2 1/8''
|
54
|
47
|
111
|
281
|
34
|
Product Video of EVR 10 1/2'' Danfoss Type Solenoid Valve:
Ordering Code of EVR Solder Connections, Normally Closed (NC) - Separate Valve Bodies:
Ordering Code of EVR Flare Connections, Normally Closed (NC) - Separate Valve Bodies:
EVR Solenoid Valve Parts For you to choose:
Solenoid Valve Armature Assembly Solenoid Valve Coil
More Refrigeration Valve For you to choose:
Danfoss Type Solenoid Valve Ammonia Solenoid Valve Castel Type Solenoid Valve
Expansion Valve Refrigerator Solenoid Valve
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
