3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072

3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072

3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072
video
3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: EVR 6
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 4-7 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Refrigeration Solenoid Valve Ordering Number: 032F8072, 032L8072
Port Size: 3/8'' (10mm) Connection Type: Flare (SAE)
Function: 2 Way, Normally Closed Voltages: 12VDC, 24VDC, 24VAC, 110VAC, 120VAC, 220VAC, 230VAC
Body Material: Brass Seal Material: PTFE
System Line Application: Discharge Line, Hot Gas Defrost Line, Liquid Line, Suction Line Application: Chiller, Freezer, Air Conditioning, Cooler, Etc
High Light:

3/8'' Refrigeration Solenoid Valve

,

Danfoss EVR 6 3/8''

,

Danfoss 032F8072

3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072



The shown is danfoss type EVR 6 solenoid valve, 3/8'' (10mm) SAE flare port size, 2 way normally closed, 12V DC, 24V DC, 24V AC, 110V AC, 220V AC voltages (other voltages can be customized), ordering code: 032F1212, 032L1212.



A solenoid valve is an electronically operated device. The valve is commonly used to replace a manual valve or where remote control is desirable. A solenoid is operated by opening and closing an orifice in a valve body that permits or prevents flow through the valve. The orifice is opened or closed through the use of a plunger that is raised or lowered within a sleeve tube by energizing the coil. The bottom of the plunger contains a compatible sealing material, which closes off the orifice in the body, stopping flow through the valve.



Main Dimension of EVR Series Solenoid Valve:

       3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072 0           3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072 1



Model
Port Size
H1
H2
L
L2
SAE (Flare)
ODF (Solder)
Inch
mm
mm
mm
mm
mm
EVR 3
EVR 3
1/4''
6
14
71
102
7
EVR 3
EVR 3
3/8''
10
14
73
117
10
EVR 6
EVR 6
3/8''
10
14
79
111
10
EVR 6
EVR 6
1/2''
12.8
14
79
127
10
EVR 10
EVR 10
1/2''
12.8
16
79
127
10
EVR 10
EVR 10
5/8''
16
16
79
160
12

EVR 15
5/8''
16
19
86
176
12

EVR15
7/8''
22
19
86
176
17

EVR 20
7/8''
22
20
90
191
17

EVR 20
1 1/8''
28.8
20
90
214
22

EVR 22
1 3/8''
35
20
90
281
25

EVR 25
1 1/8''
28.8
38
138
256
22

EVR25
1 3/8''
35
38
138
281
25

EVR 32
1 3/8''
35
47
111
281
25

EVR 32
1 5/8''
42
47
111
281
29

EVR 40
1 5/8''
42
47
111
281
29

EVR 40
2 1/8''
54
47
111
281
34



Product Video of EVR 6 3/8'' Danfoss Type Solenoid Valve:



Ordering Code of EVR Solder Connections, Normally Closed (NC) - Separate Valve Bodies:

3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072 2



Ordering Code of EVR Flare Connections, Normally Closed (NC) - Separate Valve Bodies:

3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072 3



EVR Solenoid Valve Parts For you to choose:

armature3/8'' Refrigeration Solenoid Valve Danfoss Type EVR 6 032F8072 5

          Solenoid Valve Armature Assembly                                    Solenoid Valve Coil





More Refrigeration Valve For you to choose:

danfoss refrigeration solenoid valveammonia refrigeration solenoid valvecastel refrigeration solenoid valve

    Danfoss Type Solenoid Valve         Ammonia Solenoid Valve          Castel Type Solenoid Valve

Refrigeration 2solenoid valve refrigerator

               Expansion Valve             Refrigerator Solenoid Valve
