BFEC 2/2 Way NC Dust Collector Pulse Jet Solenoid Valve Stem

BFEC 2/2 Way NC Dust Collector Pulse Jet Solenoid Valve Stem

This armature plunger is used for new version BFEC pulse valve repair kit. The related bfec pulse jet valves, solenoid coils and diaphragms are also supply. Welcome to your any inquiry and problem.

A solenoid valve is made up of two basic functional units.They are

(1) The solenoid, an electro-magnet with a plunger.
(2)A valve containing an orifice in which a disc or plug is positioned to stop or allow flow.

The valve is opened or closed by movement of the magnetic plunger,or core, which is drawn into the solenoid when the coil is energised (an electric current is passed through it). The solenoid valve opens when energized allowing instrument air to pass through, the valve closes when the solenoid is de-energized preventing instrument air from passing through but vented to the atmosphere.

Solenoid valves have a solenoid mounted directly on the valve body with the solenoid core attached to the valve stem.The core is enclosed and free to move in a permanently sealed tube inside the solenoid coil.This construction provides a compact, leak tight assembly.

BFEC Pulse Valve Armature:

Picture	Dimension	Brando Model	BAPC213050375
		Function	2 Way, Normally Closed
		Seat	Flange
		Core Tube Material	Stainless Steel
		Seal Material	NBR
		Voltage	AC, DC
		Fitted Valve	BFEC New DMF Series Pulse Valves

Picture	Dimesion	Brando Model	BB13541204
		Voltage	24VDC, 220VAC
		Power	25VA, 20W
		Fitted Armature Plunger	BAPC213050375
		Fitted Valve	BFEC New DMF Series Pulse Valves

Picture	Dimension	Brando Model	BAPC213553538
		Function	2 Way, Normally Closed
		Seat	Flange
		Core Tube Material	Stainless Steel
		Seal Material	NBR
		Voltage	AC, DC
		Fitted Valve	BFEC Old DMF Series Pulse Valves

Picture	Dimesion	Brando Model	BB13541204
		Voltage	24VDC, 220VAC
		Power	25VA, 20W
		Fitted Armature Plunger	BAPC213050375
		Fitted Valve	BFEC New DMF Series Pulse Valves

Suitable For All SBFEC Type Dust Collector Pulse Jet Valve:

Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the pulse controller. Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.

According to the valve structure:
* Right Angle Type
* Submerged Type
* Quick Mount Type
* Straight Through Type
* Flanged Type

Brando Solenoid Valve Armature Production Video:

Related product supply:

* Solenoid Valve Coil:

* Diaphragm Repair Kit:

* Pulse Jet Valve:
