Best-Nr.0200 NC SS304 Solenoid Valve Plunger Armature Assembly

Best-Nr.0200 NC SS304 Solenoid Valve Plunger Armature Assembly

Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.

Diaphragm type solenoid valves are available in a wide range of materials to suit almost any industrial application and process media. Valve diaphragm materials include NBR, Viton, EPDM and PTFE, and more exotic materials are available for specialist duties. When choosing a solenoid valve, it is important to check the chemical compatibility of the valve diaphragm material in order to ensure longevity and suitability of the valve in your application.

Detailed Images of Pulse Valve Armature:

Dimension & Data of Pulse Valve Armature:

Dimension	Model	BAPC213043091
	Funtion	2 Way, Normally Closed
	Seat	M16x1 Thread
	Core Tube Material	Stainless Steel
	Seal Material	NBR
	Voltage	AC, DC
	Fitted Coil	Best-Nr.0200
	Fitted Valve	Pulse Valve

Dimension	Model	Best-Nr.0200
	Voltage	24VDC, 220VAC
	Power	18VA, 15W
	Fitted Armature Plunger	BAPC213043001
	Fitted Valve	Pulse Valve

Brando Solenoid Valve Armature Production Video:

Related product supply:

* Solenoid Valve Coil:

* Diaphragm Repair Kit:

* Pulse Jet Valve:
