| Place of Origin: | Ningbo, China |
| Brand Name: | BRANDO |
| Certification: | CE, ISO |
| Model Number: | EVRA 32 |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | T/T, Western Union, Paypal |
| Supply Ability: | 20000 sets per month |
| Product Name: | Ammonia Solenoid Valve | Function: | NC |
|---|---|---|---|
| Connection Type: | Flange | Body Material: | Cast Iron |
| Operation: | Servo Piston | Manual Operation Option: | Yes |
| Working Pressure: | 0.2 To 42 Bar | Coil Type: | BE, BF, BG |
| Coil Voltage: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | Ordering Code: | 042H1126, 042H1127, 042H1131, 042H1140, 042H1141, 042H1190 |
| High Light: | Danfoss EVRA 32,Danfoss Ammonia Solenoid Valves,Danfoss Solenoid Valve For Ammonia |
||
EVRA 32 EN-JS1025 Danfoss Type Ammonia Solenoid Valve 042H1126 042H1131
EVRA 32 ( EN-JS1025 ) ammonia solenoid valve; 042H1126, 042H1127, 042H1131, 042H1140, 042H1141, 042H1190 ordering code; flange connection type. EVRA 32 is a servo operated piston solenoid valve.The valves are closed with currentless coil.The servo piston with main valve plate closes against the valve seat by means of the differential pressure between inlet and outlet side of the valve, the force of the compression spring and possibly the piston weight. When current to the coil is switched on, the pilot orifice opens. This relieves the pressure on the piston spring side of the valve. The differential pressure will then open the valve. The minimum differential pressure needed for full opening of the valves is 0.2 bar.
Main Dimension of EVRA 32 Ammonia Solenoid Valve:
Video of EVRA 32 Ammonia Solenoid Valve:
Ordering Code of Ammonia Solenoid Valves:
Separate valve bodies with manual operation
|
Type
|
Connection
|
Required Coil Type
|
Code No
|
|
EVRA 10
|
Flange
|
AC, DC
|
032F6210
|
|
EVRAT 10
|
AC, DC
|
032F6214
|
|
|
EVRA 15
|
AC, DC
|
032F6215
|
|
|
EVRAT 15
|
AC, DC
|
032F6216
|
|
|
EVRA 20
|
AC
|
032F6220
|
|
|
EVRA 20
|
AC, DC
|
032F6221
|
|
|
EVRAT 20
|
AC, DC
|
032F6219
|
|
|
EVRA 25
|
AC, DC
|
032F6225
|
Separate valve bodies without manual operation:
|
Type
|
Connection
|
Required coil type
|
Code No
|
|
EVRA 3
|
Flange
|
AC, DC
|
032F3050
|
|
EVRA 10
|
AC, DC
|
032F6211
|
|
|
EVRA 25
|
AC, DC
|
032F6226
|
Separate valve bodies with butt weld connections:
|
Type
|
Butt weld connection
|
Code No
|
|
|
DIN
|
ANSI
|
||
|
Valves with manual operation
|
|||
|
EVRA 32
|
1 1/4 inch
|
|
042H1126
|
|
1 1/2 inch
|
|
042H1131
|
|
|
|
1 1/4 inch
|
042H1140
|
|
|
|
1 1/2 inch
|
042H1141
|
|
|
EVRA 40
|
1 1/2 inch
|
|
042H1128
|
|
2 inch
|
|
042H1132
|
|
|
|
1 1/2 inch
|
042H1142
|
|
|
|
2 inch
|
042H1143
|
|
