ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem
video
ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: K0950
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Individual Boxes, Carton, Pallet
Delivery Time: 5-8 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: ASCO Pulse Valve Armature, ASCO Pulse Valve Plunger, ASCO Pulse Valve Stem Function: 2 Way, Normally Closed
Kind Of Current: AC, DC Armature Tube Material: Stainless Steel
Seal Insert Material: NBR (Nitrile) Connection Type: M23.8x1 Thread
Fitted Solenoid Coil: 400425 Fitted Pulse Valve: SCG353A047, SCG353A50, SCG353A051
High Light:

Pulse Solenoid Valve Stem

,

K0950 Solenoid Valve Stem

,

ASCO Type K0950 Armature

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem



This is solenoid valve stem for asco 1 1/2'' SCG353A047, 2'' SCG353A050 and 2 1/2'' SCG353A051 pulse valve repair kit. The related pulse jet valves, solenoid coils and diaphragms are also supply. Welcome to your any inquiry and problem.



The armature assemblies are constructed of metallic components designed to provide protection against incompatibilities of various fluid medias. However it is necessary to use caution when specifying a solenoid valve for an unfamiliar fluid. Use caution when selecting a material suited specifically for the media.



The Armature Tube is the stainless steel or brass tubular element used as a guide for the movable core which is actuated by the magnetic force generated by the coil.



The Plunger of a solenoid is normally made from a ferrous compound. Ferrous or iron based materials have a natural magnetism as their molecules constantly try to align themselves with the earth's own magnetic fields which are generated from the earth's iron / ferrous core. This process results in a ferrous material having natural magnetic poles created by its own magnetic fields. It is important that the core of a solenoid has ferromagnetic properties as the poles created are a primary component of transforming the electrical energy into mechanical energy.



ASCO Pulse Valve Armature:

Picture Dimension
Brando Model
BAPC214041405
ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 0 ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 1
Reference Number
K0950
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Voltage
AC, DC
Function
2 Way, Normally Closed
Fitted Coil
400425
Fitted Valve
1 1/2'' SCG353A047,
2'' SCG353A050,
2 1/2'' SCG353A051




Picture Dimesion
Brando Model
BB14040007
1'' SCG353A044 ASCO Pulse Valve Repair Kit Solenoid Stem 6 1'' SCG353A044 ASCO Pulse Valve Repair Kit Solenoid Stem 7
Reference Number
400425
Voltage
24VDC, 48VDC,
24VAC, 48VAC,
115VAC, 230VAC
Fitted Armature Plunger
K0950
Fitted Valve
1 1/2'' SCG353A047,
2'' SCG353A050,
2 1/2'' SCG353A051



Picture Dimesion
Brando Model
BAPC211037301
ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 4 ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 5
Reference Number
K0850
Plunger Tube Material
Stainless Steel
Seal Material
NBR
Voltage
DC, AC
Function
2 Way, Normally Closed
Fitted Coil
400325
Fitted Valve
3/4'' SCG353A043,
1'' SCG353A044



Picture Dimesion
Brando Model
BB11036001
1'' SCG353A044 ASCO Pulse Valve Repair Kit Solenoid Stem 2 1'' SCG353A044 ASCO Pulse Valve Repair Kit Solenoid Stem 3
Reference Number
400325
Voltage
24VDC, 48VDC,
24VAC, 48VAC,
115VAC, 230VAC
Fitted Armature Plunger
K0850
Fitted Valve
3/4'' SCG353A043,
1'' SCG353A044



Brando Solenoid Valve Armature Production Video:

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 8



Related product supply:



* Solenoid Valve Coil:

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 9

* Diaphragm Repair Kit:

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 10



* Pulse Jet Valve:

ASCO Type K0950 14mm OD Dust Collector Pulse Solenoid Valve Stem 11



FAQ:



How can you tell if your solenoid is bad?
If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out coil, you need to troubleshoot the valve solenoids.



What is a solenoid?
A solenoid is an electric coil that is wrapped around a ferromagnetic substance (such as iron) that acts as an electromagnet when the current is passed through it.



How does a solenoid work?
When the electric current is passed through the coil, an electromagnetic field is created. This electromagnetic field causes the plunger to move up or down. This mechanism is used by solenoid valves to open or close the valve.



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
