13mm Hole Diameter ERA SIB Type Hydraulic Solenoid Valve Coil

13mm Hole Diameter ERA SIB Type Hydraulic Solenoid Valve Coil

  • 13mm Hole Diameter ERA SIB Type Hydraulic Solenoid Valve Coil
13mm Hole Diameter ERA SIB Type Hydraulic Solenoid Valve Coil
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BB13038510
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Hole Size: 13mm Height: 38.5mm
Width: 36.0mm Connection Type: DIN43650A
Voltage: 10VDC, 12VDC, 24VDC, 110VAC, 220VAC Power: 23W, 24VA
Insulation Class: H Protection Class: IP65
Reference Number: 31400 Application: ERA SIB Type WF0.5H/WF0.6H/WF0.9/WF1/JA1BXN/W0.6/EN52060/EN52081-06 Solenoid Valve
High Light:

13mm Hole Diameter Hydraulic Solenoid Valve Coil

,

ERA SIB Type Solenoid Valve Coil

,

WF0.5H WF0.6H Hydraulic Coil

 13mm Hole Diameter ERA SIB Type Hydraulic Solenoid Valve Coil



This 31400 solenoid valve coil is applied to ERA SIB Type WF0.5H/WF0.6H/WF0.9/WF1/JA1BXN/W0.6/EN52060/EN52081-06 Solenoid Valves. It is made of thermosetting material. The most common material for thermosetting of electromagnetic coil is BMC material. It is a material with high temperature resistance and waterproof preference and has good resistance. High-pressure capability, while electromagnetic coil thermoplastics are most commonly PA66 glass-containing materials, which are faster to mold and relatively lower in cost than BMC. Our solenoid valve coils are protected to IP65. You need to provide us with a series of solenoid valve coil data, such as the pressure of the solenoid valve coil, the material of the solenoid valve body, the interface size and the media, etc., and then we will recommend the most suitable product for you.



Technical data of ERA SIB Type 31400 DC24V/AC220V Solenoid Coils:



Model number BB13038510
Normal voltage DC12V/DC24V/AC110V/AC220V (Other can be customized)
Normal power AC: 18VA 30VA DC:14W 18W
Insulation class H
Connection DIN43650A
Application ERA SIB Type WF0.5H/WF0.6H/WF0.9/WF1/JA1BXN/W0.6/EN52060/EN52081-06 Solenoid Valve
Weight 211 g
Hole size 13 mm
Height 38.5 mm
Width 36 mm



Overall dimension of ERA SIB Type WF/0.5HWF0.6H Solenoid Coils:
Overall dimension of ERA SIB Type WF/0.5HWF0.6H Solenoid Coils



Detail enlargement of WF0.9/WF1/JA1BXN electromagnetic Valve Coils:

Detail enlargement of WF0.9/WF1/JA1BXN electromagnetic Valve Coils



Brando offers a wide range of solenoid valve coils, which designed into various types, mainly features encapsulated coils, including thermoplastic and thermosetting. Our coils have the characteristics of High Performance, High Reliability and Long Service Life, can be used for Different Applications. We also provide excellent Customized Service.



Solenoid Coil Main Features:

1. Heat resistant bobbin moulded with thermoplastic polyester material;
2. High quality Enameled copper wire, F, H, N different insulation class for choose;
3. Built-in magnetic yoke, made by low carbon iron;
4. Encapsulation with high quality specially designed thermosetting & thermoplastic material.



Solenoid Coil Main Structure:

The conventional structure of a solenoid valve coil includes: Framework, Enameled copper wire, PIN, Yoke and Encapsulation. In addition, according to the actual use, there will be a magnetizing guide ring, a rectifier bridge be used for rectifying, etc.



Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
