Vickers Type Hydraulic Solenoid Valve Coil 507847 12V DC 30W

Vickers Type Hydraulic Solenoid Valve Coil 507847 12V DC 30W

Vickers solenoid coil, also called Vickers coil, Eaton Vickers solenoid coil or Eaton solenoid coil. Just like Rexroth solenoid coil and Yuken solenoid coil, Vickers solenoid coil is a necessary part of Vickers solenoid or Vickers solenoid valve. By the voltage, Vickers solenoid coil can be divided into AC and DC type.

Replacement solenoid coils are needed in hydraulic systems when the solenoid coil used to control a hydraulic solenoid valve wears out or stops functioning. A solenoid is an electromagnet that consists of a tightly wrapped metal coil around a solid metal core. They produce a controlled, uniform magnetic field, and the metal coil can be inserted or removed which creates a method of control for various devices, including a hydraulic valve.

How do solenoid coils work in a hydraulic system?
In a hydraulic solenoid valve, solenoids are used to control the flow of fluid. Most commonly, they are used as a low-power switch that opens and closes a pilot valve, which in turns controls the main valve by applying pressure to a connected piston or diaphragm.

Dimension & Data of Hydraulic Solenoid Valve Coil:

Picture	Dimension	Model	BB23660411
		Ref. No	507847 (12V) 507848 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	DIN43650A
		Insulation Class	F
		Protection Class	IP65

Picture	Dimension	Model	BB23660407
		Ref. No	02-124661 (12V) 02-124662 (24V)
		Voltage	12VDC, 24VDC
		Power	30W
		Connector Type	AMP
		Insulation Class	F
		Protection Class	IP67

Picture	Dimension	Model	BB23745310
	​	Ref. No	02-101732, 02-101731
		Voltage	110VAC, 220VAC
		Power	17W
		Connector Type	Flying Leads
		Insulation Class	H
		Protection Class	IP67

Picture	Dimension	Model	BB23745309
		Ref. No	02-101727 (220V) 02-101726 (110/120V)
		Voltage	110VAC, 220VAC
		Power	17W
		Connector Type	DIN43650A
		Insulation Class	H
		Protection Class	IP65

Brando Factory Production of Solenoid Valve Coil:

Other hydraulic solenoid valve coil fo you to choose:

Bosch Rexroth Type Hydraulic Solenoid Valve Coil:

Yuken Type Hydraulic Solenoid Valve Coil:
