DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC

DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC

DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC
video
DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC
Product Details:
Place of Origin: Ningbo, China
Brand Name: BRANDO
Certification: CE
Model Number: DIN 43650C
Payment & Shipping Terms:
Minimum Order Quantity: 3pcs
Price: negotiation
Packaging Details: decades ad box,then put into carton
Delivery Time: 4-7 work days
Payment Terms: L/C, T/T, Western Union, D/A
Supply Ability: 6000pcs per two days
Contact Now
Detailed Product Description
Part Name: Solenoid Coil Connector DIN Type: DIN 43650 Form C
Distance: 9.4mm Gender: Female
PIN Number: 3 PIN Form: 2+1GND, 3+1GND
Wokring Voltage: AC380V, DC300V Protection Class: IP65
Nomical Current: 10A Contact Resistance: ≤5mΩ
Max Conductor Section: 3x0.75mm² Fixing Screw: M3x25
LED: Available
High Light:

DIN 43650 Type C Connector

,

DIN43650C Connector

,

Solenoid Valve Electrical Connector

DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC


DIN 43650 solenoid connectors are durable valve connectors used across a wide range of industrial applications and are usually not affected by voltage surges or electro-magnetic interference.



Available in three formats: Form A, Form B or Form C. DIN 43650 solenoid connectors are designed to function within certain voltage limits. Gasket options for DIN connectors include - oil resistant NBR or ozone and heat resistant EPDM.



DIN 43650 solenoid connectors can be found in many industrial applications including machine building and tooling or equipment manufacturing processes, facilitating power and signal transmission in magnetic valves, sensors and pressure transducers.



Dimension & Data of Solenoid Coil Connector:



DIN 43650A Connector:

Dimension
DIN Type
DIN 43650 Form A
DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC 0
Distance
18mm
Form
2+1GND, 3+1GND
Protection
Class
IP65
Working
Voltage
AC380V, DC300V
Fixing Screw
M3x28
Nomical Current
10A
Contact Resistance
≤5mΩ
Max Conductor Section
3x1.5mm²



DIN 43650B Connector:

Dimension
DIN Type
DIN 43650 Form B
DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC 1
Distance
11mm
Form
2+1GND, 3+1GND
Protection
Class
IP65
Working Voltage
AC380V, DC300V
Fixing Srew
M3x30
Nomical Current
10A
Cntact Resistance
≤5mΩ
Max Conductor Section
3x1.5mm²



DIN 43650C Connector:

Dimension
DIN Type
DIN 43650 Form C
DIN 43650 Type C DIN43650C Solenoid Valve Coil Connector 24VDC 2
Distance
9.4mm
Form
2+1GND, 3+1GND
Protection Class
IP65
Working Voltage
AC380V, DC300V
Fixing Screw
M3x25
Nomical Current
10A
Cntact Resistance
≤5mΩ
Max Conductor Section
3x1.5mm²



Brando manufactures an extensive and comprehensive range of internal- and external-thread connectors conforming to industry standard EN 175301-803 (formerly DIN 43650). Standard options include LED illuminated devices as well as VDR, diodes to offer protection against overvoltage peaks. Solenoid coil connectors offer protection from dust and water when correctly installed with screw and gasket which are supplied together with the connector.



Brando's field-attachable, external-nut design is mechanically superior to traditional internal-nut DIN valve connectors, achieving greater cable retention and improved sealing to IP67. Standard internal thread DIN valve connectors are IP65 rated and available with different thread style, gaskets and circuitry options.
